Standard_equipment
- Electric motor drive: 21 kW; electric motor working hydraulics: 9,7 kW
- Electric four wheel drive with cardan shaft
- Li-Ion battery pack, 240 V / 15.65 kWh (31.3 kWh on option)
- On-board charger with Type 2 connector enables charging at a 230V power outlet or a wallbox
- Charging cable type 2 / CEE 16 A, 4 m
- Battery management system
- Energy recuperation
- Hill-Hold funktion: ?start up assistant? to make hill starts easier
- Tyres 10.0/75-15.3 AS, offset +40
- 20 km/h
- Eco mode to extend the operating time
- Genuine Schäffer axle, 6 hole
- Water cooling of electric motors
- Multiple disk brake, maintenance free; service and parking brake
- Maintenance free articulated pendulum joint
- Restraining system for protection roof
- LED working headlights: 2 x front, 1 x rear
- Acoustic reverse warning signal (can be switched off)
- Parallel lift
- Electronically operated additional controller
- Working hydraulics: 42 l/min
- Adjustable steering column
- Hour meter and charging status display
- Rear weight end plate
- Main battery switch
- Driver-on-board switch
- Quick-change frame SWH with hydraulic tool lock
|
|
Technical_data
- Engine
- Output: Electrical drive: 21 kW
- Working hydraulics: 9,7 kW
- Tyres
- Standard tyres: 10.0/75-15.3 AS, ET+40
- Option I: 27x10.5-15 SKD, ET+40
- Option II: 31x15.5-15 AS, ET-37
- Electric system
- Dimensions
- (A) Wheelbase: 1,550 mm
- (B) Chassis length: 3,230 mm
- (C) Overall length with standard bucket: 3,880 mm
- (D) Digging depth: 90 mm
- (G) Loading height with pallet fork / option: 2,680 / 2,960 mm
- (H) Max. dumping height / option: 2,045 / 2,300 mm
- (I) Front end height / option: 1,690 / 1,790 mm
- (J) Dumping width: 470 mm
- (K) Seat height: 1,160 mm
- (L) Protective roof height: 2,190 mm
- (L) Cab height: 2,140 mm
- (M) Max, bucket pivot point / option [mm]: 2,880 / 3,110 mm
- (N) Overall width / option: 1,020 (1,200 turned) / 1,030 - 1,570 mm
- (O) Inner turning radius: 1,200 mm
- (P) Outer turning radius: 2,220 mm
- (Q) Outer radius with standard bucket: 2,865 mm
- Drive
- Traction hydraulics: 4-wheel-drive, fully electric
- Axles: Original Schäffer axles, 6 wheel nut rim
- Speed: 0 - 20 kph with Eco mode
- Brakes and steering
- Service braking system: Combined brake hydrostatic and multi-disc brake
- Parking brake: Multi-disc brake running in oil bath
- Steering: Fully hydraulic articulated/swivel steering
- Tank capacity
- Working hydraulics
- Delivery rate: 42 l/min
- Operat. pressure: 180 bar
- Weights
- Operating weight protective roof incl. Original tyres, driver and standard bucket: 2,240 kg
- Operating weight cabin incl. Original tyres, driver and standard bucket: 2,305 kg
- Lifting capacity: 1,700 kg
- Tipping load, straight, pallet fork acc. to ISO 8313: 1,048 - 1,321 kg
- Tipping load, straight, bucket acc. to ISO 8313: 1,250 - 1,578 kg
- Sounds and vibration
- Sound pressure level LpA: 64 db(A)
- Sound power level guaranteed LwA: 99 db(A)
- Sound power level equivalent LwA: 90 db(A)
- Hand/arm vibration acc. to ISO 8041: <2,5 m/s²
- Total body vibration acc. to ISO 8041: <0,5 m/s²
|
 Dimensions
|
|
Tyres_loader
| Dimension |
Diameter (mm) / Width (mm) |
Rim offset |
Loader width (mm) |
Tread |
Tread options |
| 10.0/75-15.3 |
770 / 260 |
40 |
1,020 (1,200) |
AS |
MPT |
| 10.0/75-15.3 |
770 / 260 |
-5 |
1,100 |
AS |
MPT |
| 31x15.5-15 |
770 / 400 |
-37 |
1,300 |
AS |
SKD, Allground |
| 27x10.50-15 |
690 / 270 |
40 |
1,030 |
SKD |
|
| 31x13.5-15 |
800 / 350 |
-35 |
1,250 |
Multi Trac |
|
| With wide axle |
|
|
|
|
|
| 10.0/75-15.3 |
770 / 260 |
40 |
1,280 |
AS |
MPT |
| 10.0/75-15.3 |
770 / 260 |
-5 |
1,370 |
AS |
MPT |
| 31x15.5-15 |
770 / 400 |
45 |
1,390 |
AS |
SKD, Allground |
| 31x15.5-15 |
770 / 400 |
0 |
1,480 |
AS |
SKD, Allground |
| 31x15.5-15 |
770 / 400 |
-45 |
1,570 |
AS |
SKD, Allground |
| 31x13.5-15 |
800 / 350 |
-35 |
1,520 (1,380) |
Multi Trac |
|
|
