Penta DOUBLE AUGER TRUCK MOUNT 9630

Listing image Listing image Listing image Listing image
Specifications

Model 9630 Category Name Trailers Year 2024
Sale Type New Manufacturer Penta Total Width 101 in
Empty Weight 23,547 lbs Total Length 333 in Capacity 9" Rubber 965 cu ft
Price Contact for price CAD
Description

DOUBLE AUGER TRUCK MOUNT
TRUCK REQUIREMENTS
HP 425 - 475
Front Axle 20,000 lbs
Rear Axle 46,000 lbs
Preferred Transmission Allison 4500RDS
Cab to Axle (A) 175"
End of Frame (B) 96"
Overall Height (C) 130"
Approximate Overall Height w/rubber (D) 136"
Conveyor Clearance (E) 44"
Corner Door 26"
FEATURES

CONTROLS

  • Digital Screen
  • Joystick
  • Oil Temperature Monitor
  • Oil Pressure Monitor
  • Optional Cameras

CONVEYOR

Conveyors are configured to match the individual needs of the operator.

  • Dog Leg System
  • Slide Out Conveyors
  • Designed to be Grain Ration Ready

TUB & AUGER

The angled curve of the tub and baffles are designed to work with our Hurricane augers for the best mix possible and provides easy clean out.

  • Stainless Steel Tub Liner included in the truck mount mixers increases the longevity of the life of the tub
  • Massive front and rear material doors increase efficiency in unloading and clean out

DRIVE SYSTEM

  • Hydraulic Pumps
  • Poclain Wheel Motors
  • Hoses
  • Oil Reservoir
  • Valve Blocks
  • Mechanical Truck Mount available for models 4130 and 5030
