Description
|
OVERVIEW
With a combination of our Lean Burn technology, a semi-direct intake system and a high performance compression ratio of 10.2-to-1, these new outboards deliver clean, efficient power. Compared to the current 175 and 150, the DF175A is 14% more fuel efficient and the DF150A shows a 7% improvement for significant savings at the fuel dock
|
|
Features
|
EXPLANATION
The engine powerhead is offset closer to the transom, moving the outboard’s center of gravity forward.
ADVANTAGE
Less vibration More compact engine Stable steering performance
EXPLANATION
This system which incorporates the Offset Driveshaft features a first stage reduction between the crankshaft and drive shaft and a second stage reduction inside the gear case. This design makes a larger gear ratio possible, allowing it to turn a large diameter propeller for high propulsive efficiency while providing greater torque.
ADVANTAGE
High propulsive efficiency with large diameter propeller. Powerful navigation, maintaining propeller rotation even with a larger load. Power to turn large diameter propellers, offering quick acceleration.
|
|
Suzuki Advantages
|
Model Name: |
DF175 |
175 Verado™ |
|
Manufacturer: |
Suzuki |
Mercury |
|
Horsepower: |
175 |
175 |
|
Shaft Length (Inches): |
L (20), X (25) |
L (20), X (25) |
|
Weight (Lbs): |
L (474), X (485) |
L (510), X (527) |
|
Cylinders: |
In-line 4 |
In-line 4 |
|
Valves Per Cylinder: |
DOHC 4 Valves Per Cyl |
DOHC 4 Valves Per Cyl |
|
Valve Train Drive: |
Self adjusting oil bathed chain with variable valve timing |
Single overhead timing belt |
|
Displacement: |
174.9 cu. in. (2867 cc) |
105.7 cu. in. (1732 cc) |
|
Bore and Stroke (Inches/mm): |
3.81 x 3.81 in. (97 x 97 mm) |
3.23 x 3.23 in. (82 x 82 mm) |
|
Operating Range (RPM): |
5500-6100 |
5800-6400 |
|
Induction System: |
EFI - Multi Stage Induction |
EFI Super Charged |
|
Starting System: |
Electric Start w/ Suzuki EFI |
Electric |
|
Lubrication: |
Wet sump |
Wet sump |
|
Oil Tank Capacity: |
8.0 qt. (7.6 lit.) |
6.3 qt. (6.0 lit) |
|
Ignition: |
Solid State Electronic |
Digital Inductive |
|
Alternator: |
12V 44A |
12V 70A |
|
Trim Type: |
Power Trim and Tilt |
Power Trim and Tilt |
|
Gear Ratio: |
2.50:1 |
2.08:1 |
|
CARB Emissions Rating: |
3-Star Ultra Low |
2-Star Very-Low |
|
Standard Propeller (Blades x Dia. x Pitches (Ins.)): |
Optional - See Dealer |
Unknown |
|
Counter Rotation: |
Available |
Available |
|
Range of Avail. Optional Propeller Pitches: |
17 - 27 |
Unknown |
|
Steering: |
Remote |
Unknown |
|
|
|
