Features
|
|
 Blower
The field proven Heavy Duty 5.3 Positive Displacement Blower is the heart of the system. Castings are machined to strict tolerances to assure maximum efficiency that allows you to move grain a greater distance without using one or more expensive booster type systems.
|
 Airlock
To achieve and maintain best performance, the airlock components are precision machined. The steel rotors are fitted with adjustable steel tips to allow the operator to keep the airlock working at peak performance at all times. The rotor is driven by a reversible, pressure protected, hydraulic motor.
|
 Silencer
The high efficiency silencing system reduces noise intensity by over 50% with absolutely NO reduction in machine capacity. Our unique silencing design provides greater operator comfort for years of satisfaction.
|
 Pre-Cleaner Dust Separation Tank
The heavy duty displacement blower is protected from dust that is removed in the pre-cleaner tank, thereby, giving the Conveyair blower “years of trouble free performance”. |
 Camlock Couplers
The quick connect couplers provide a tight fit to assure that maximum vacuum and pressure is maintained. The quick connect feature makes it easy to add or remove extensions when filling tall silos or long distance grain movement is required. |
 Cogged belt and pulley system
Model 6644 grain vac comes standard with a cogged belt and pulley system to minimize slippage which prevents power loss to the blower. An idler pulley tension system maintains belt tension. (Shown with cover removed) |
 Receiver Tank
The receiver tank comes standard with a removeable, bolt-on lid and liner. |
 Pressure and Vacuum Gauge Kit
The 6644 is equipped with a pressure and vacuum gauge kit (gauge is shown in operation). |
