Kverneland cultivator CLC pro

Listing image Listing image Listing image Listing image
Specifications

Model cultivator CLC pro Category Name Agriculture Year 2018
Sale Type New Manufacturer Kverneland Price Contact for price CAD
Description

 Stubble Cultivator CLC pro


The CLC pro has been especially designed to work with the most powerful tractors. With 240HP maximum for 9'8" (3.00m) and up to 350HP for the 16'4" (5.00m) folding model, the CLC has become the benchmark regarding admissible power. It can, therefore, be combined with any type of roller and accessories which makes it  extremely versatile. This quality to absorb the strongest forces also ensures a very long durability.
The CLC range can be equipped with two types of tines and a wide selection of shares. According to the operation requested and
the type of soil, the large choice of following implements allows to carry out all sorts of cultivation: from stubble cultivation at 5cm
to deep loosening at 30cm working depth.
The great versatility of the CLC pro makes it the ideal implement to meet all your requirements.
 The Advantages:
  • High Horse power capacity to cope with all conditions and tractor sizes from 90 to 350 hp
  • Universal Cultivator from  9'8" to 16'1" (3.0 to 4.9m), working 5 to 30cm deep
  • 3 bar frame for optimum mixing and blockage free operation
  • Unique leg design vibrating for intensive effect in the soil but low fuel consumption
  • Wide choice of shares, rear rollers and levelling equipment
  • Intensive mixing of the residues
  • Seedbed finish possible
Model Working width Frame No. of tines Average tine spacing Min./Max. HP
CLC pro 300 9'8" (3.0m) rigid 10 280 120 / 240
CLC pro 350 11'5" (3.5m) rigid 12 280 135 / 270
CLC pro 400 13'1" (4.0m) rigid 14 280 165 / 300
CLC pro 400F 13'1" (4.0m) fold 13 290 185 / 300
CLC pro 500F 16'4" (5.0m) fold 17 290 200 / 350
Highlights

Strong Frame CLC pro

KV_clc pro_0026.jpg
  • The frame design and heavy-duty central beam offers in-field durability even under extreme working conditions.
  • The machine offers high underbeam clearance with 870mm to cope with incorporation of high volumes of crop residue.
  • The frames can absorb e.g. 240 hp with 3.00m and up to 350hp for the folding implements with 5.0m.
  • The material used can bear significant loads while staying reliable and light.
  • The weight carried by the tractor is thus reduced and helps saving fuel.
  • The CLC pro Classic is 50cm shorter than the CLC pro, shifting the centre of gravity closer to the tractor.

Tines and Shares

KV_tine technology_0012.jpg
  • The unique and robust design of the tines incorporates a specially heat treated hollow “C” profile.
  • The heat treatment is of the same standards as the beams on the Kverneland ploughs.
  • The tine leg can withstand sideway movements of up to 20cm. This means lower stress to the tine holder and frame structure.
  • The CLC tines are suitable to work at 40 cm depth to fight plough pans and to encourage natural drainage, even in stony soils.
  • The removal of soil compaction allows intensive rooting in the lower soil layers. The plants therefore gain access to nutrients and water reserves at these deeper soil levels.
  • For operation in rather abrasive soil, Kverneland offers the option of carbide faced shares and wing shares (not recommended for stony soil).
  • The carbide faced parts last 5 to 12 times longer than the standard ones
  • The wing share is the right choice for shallow stubble cultivation.
  • The CLC Evo Wings is still very versatile. The wings can be removed to work deeper with just the reversible tines

Leaf Spring/Vibromat

KV_tine technology_0008.jpg
  • For lighter conditions Kverneland offer the CLC tine with shearbolt overload protection.
  • This version of the CLC tine offers the same high quality as that of the „Auto-reset“ tine, and is releasing from 2 tons.
  • The Kverneland CLC tine equipped with the “Auto-reset“ leaf spring safety system is the perfect choice for hard and stony conditions.
  • The well renowned Kverneland leaf spring protects the tines against overload.
  • The release pressure can be adjusted if required.
  • All pivot points of the CLC tines are manufactured with wear resistant bushes and bolts of the renowned Kverneland quality.
  • Therefore the CLC tine system is maintenance-free

Rear Accessories CLC Evo

There is a full range of levelling equipment and rear rollers available:

Levelling discs

  • Rubber spring loaded, to follow the ground and protect
  • Border discs as standard

Levelling tines

  • Good levelling capacity
  • Good following of the ground contou

Combi disc harrow:

  • Combination of a single disc gang with all roller type

Double disc gang diameter 510 mm

  • Leaves a rough surface with aggregates ready for wintering, interesting at the end of autumn season for preparing spring fields and crops

Flexline diameter 585mm

  • Good reconsolidation of light soil
  • Universal and suitable for all soil types

Cage roller diameter 550mm

  • 10 bars for a good loading  capacity and operation in wet conditions
  • Effective crumbling action

Double cage roller diameter 400mm (tube/flat)

  • Good crumbling
  • Precise depth control

Actipack:

  • The Kverneland Actipack roller displays its superb working qualities especially on medium to heavy soils.
  • The integrated cutting discs break the larger clods whilst the adjustable knives cut the remaining clods resulting in optimal clod breakdown.

Actiring:

  • The Actiring roller is a lighter variant of the Actipack, using the same frame structure and knife system.
  • The discs have been replaced by a “V” profile ring, this is saving 50kg/m, which is of critical importance for reducing lifting requirements for mounted equipment.
