SnowEx® Brine Pro™ 2000

Videos
Call for Price
Overview

Brine Pro™ 2000

Now, just about anyone can make brine. That’s because the Brine Pro™ 2000 brine maker simplifies production with user-friendly operation, automatic salinity control and easy no-splash salt refilling. Basically, it removes all guesswork from the process, helping contractors confidently take brine making into their own hands. Plus, the system is compatible with low-flow water input and 220VAC electrical sources that are available in most shops. It doesn’t get any easier than this.

Brine Pro™ 2000

Touch-Screen Controls

  • Intuitive full-color touch-screen interface.
  • 3 modes: automatic, batch and cleaning.
  • Multilingual display capabilities.

Hammer Mill Salt Grinder

  • Receives material from the unique flow control system.
  • Grinds salt to a consistent particle size and delivers it to the mixing chamber.
  • Accelerates the dissolve rate.
  • Expedites the clean-out process.
Features

Full-Trip MoldboardTouch Screen Controls

Even the controls on the Brine Pro are simple. The touch-screen interface makes it easy to set the unit for automatic, batch or cleaning mode.



Full-Trip Moldboard Vertical Reinforcement Ribs

Six vertical ribs support the back of the blade to add strength and protect against twisting.



Full-Trip MoldboardAutomatic Salinity Control

In order for brine to be effective, it needs to have the correct amounts of salt and water. Thanks to automatic salinity control on the Brine Pro, the operator can sit back and let the machine do all the work.



Full-Trip Moldboard Material Flow Control

Precise salt delivery is key to an effective brine mixture. The unique material flow control on the Brine Pro uses a rotary vane feeder to accurately measure out the correct amount of salt to bring to the grinder.



Full-Trip MoldboardMixing Chamber

The mixing chamber includes a high-volume circulation pump. This feature helps ensure a uniform brine mixture up to 1,050 gallons per hour (3,974.7 L/h).



Full-Trip MoldboardDry Hopper System

The Brine Pro offers a no-splash solution for adding salt. Unlike most other brine makers, you don’t have to dump salt into the mixing chamber. Just add it into the 1-cubic-yard dry hopper, and the Brine Pro will take it from there. The hopper offers visual salt level indication, letting you know when it’s time to refill.



Full-Trip MoldboardEasy Clean-Out

Special cleaning mode allows for simple draining of the mixing chamber between batches.



xxxx
Imperial Brine Pro 2000
Empty Weight 1,520 lb
Overall Length 100"
Overall Height 89"
Overall Width 86"
Mixing Tank Capacity 265 gal
Brine Tank Capacity 285 gal
Hopper Volume 1 cu yd
Brine Production Up to 1,050 gal/h
Inlet Flow Rate Up to 15 gpm
Electrical Connection 220VAC, single phase
Auger Motor 1/3 hp, 3-phase variable speed motor with transmission
Hammer Mill Motor 2 hp single phase
Circulation Pump 5 hp single phase, 210 gpm, centrifugal circulation pump
Discharge Pump 1 hp, greater than 66 gpm @ 10' head height, fully stainless steel
Controller 4-mode automatic computer controlled; touch-screen
Salinity Sensors Toroidal conductivity sensor
Frame Powder coated steel & stainless steel components
Hopper One-piece LLDPE safety yellow poly
Vibrator Standard, industrial electric 220V
Top Screen 5/16" steel rod construction with grid pattern
Mixing Tank One-piece LLDPE safety yellow poly
Brine Tank One-piece LLDPE safety yellow poly with sloped bottom for clean-out
Auger Rotary vane feed system
Hammer Mill/Grinder Stainless Steel
Metric Brine Pro 2000
Empty Weight 680.38 kg
Overall Length 254 cm
Overall Height 226 cm
Overall Width 218.44 cm
Mixing Tank Capacity 1,003 L
Brine Tank Capacity 1,078.8 L
Hopper Volume 0.765 cu m
Brine Production Up to 3.975 L/h
Inlet Flow Rate Up to 56.8 L/min
Electrical Connection 220VAC, single phase
Auger Motor 1/3 hp, 3-phase variable speed motor with transmission
Hammer Mill Motor 2 hp single phase
Circulation Pump 5 hp single phase, 795 L/min, centrifugal circulation pump
Discharge Pump 1 hp, greater than 249.8 L/min @ 3.05 m head height, fully stainless steel
Controller 4-mode automatic computer controlled; touch-screen
Salinity Sensors Toroidal conductivity sensor
Frame Powder coated steel & stainless steel components
Hopper One-piece LLDPE safety yellow poly
Vibrator Standard, industrial electric 220V
Top Screen 0.8 cm steel rod construction with grid pattern
Mixing Tank One-piece LLDPE safety yellow poly
Brine Tank One-piece LLDPE safety yellow poly with sloped bottom for clean-out
Auger Rotary vane feed system
Hammer Mill/Grinder Stainless Steel



Specifications
Model
Brine Pro™ 2000
Category Name
Snow Equipment
Year
2016
Sale Type
New
Manufacturer
