ID # 26836172

Fella Juras 1502

  • Fella Juras 1502
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Dual rotor – lateral windrow deposition – trailed

  • Single and double-swath deposition both possible
  • Neat raking, even on demanding terrain
  • Low power requirement
  • Transport width, without converting, less than 3 m

JURAS 1502

Working width approx.: 6.30 m

  1. The cardanic rotor suspension and the twistable frame ensure optimum ground adaptation in all directions and thus also neat raking work.
  2. Work flexibly thanks to infinitely variable hydraulic working width adjustment.
  • Lightweight machine: Working widths even with small tractors
  • High flexibility thanks to hydraulically adjustable working width
  • Durable FELLA rake head with enclosed design
Specifications
Model
Juras
Category Name
Agriculture
Year
2023
Sale Type
New
Manufacturer
FELLA
Machine
JURAS 1502
PTO Rpm
540 rpm
Weight Approx
1380 kg
Rotor Diameter
2960 mm
Mounting Category
Drawbar
Swath Width Approx
600-1900 mm
Power Demand Approx
45 hp
Tine Arms Per Rotor
12. Dez
Double Tines Per Arm
4
Working Width Approx
6300 / 7000 mm
Tyres Of Rotor Chassis
2x 18/8.50-8 3x 18/8.50-8
Transport Length Approx
8450 mm
Necessary Hydraulic Outlets
1x SAV, 1x DAV
Transport Width Approx. (mounted Tine Arms)
3000 mm
Transport Width Approx. (dismounted Tine Arms)
2300 mm
special features

High level of adaptability

The working width is hydraulically infinitely adjustable (from 3.10 m to 7.00 m) and therefore adapts to a wide range of conditions and crop varieties.

Perfect ground adaptation

The cardanic mechanism patented by FELLA in conjunction with the twistable frame and the large-dimensioned tyres ensure perfect ground adaptation. As a result, forage lying in recesses and depressions can be recovered without contamination or loss.

Can be adapted to the forage volume using single- or double-swath positioning

Depositing a single swath is just as possible as depositing two small single swaths or a double swath by making a return pass.
technologies

Cardanic rotor suspension

The patented fully cardanic rotor suspension ensures that perfect ground adaptation is guaranteed even under the most difficult of working conditions.

Rake heads

The rake heads from FELLA impress with their enclosed design, which
reliably protects all important components against dirt and dust. This design
guarantees a long service life. The large-dimensioned drive unit and the precision manufactured rotor arm housing made of aluminium alloy
are both good examples of modern and practice-proven design.

Cam track adjustment/work quality optimisation

With the adjustment of the longitudinal and transverse inclination of the rotor and the cam track adjustment, the rake can be easily adapted to various conditions.
literature
Download product range brochure                                                                                                                                                              Download
Download JURAS rake brochure  Download
