FELLA JURAS 1502

  • FELLA JURAS 1502
  • FELLA JURAS 1502
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Rakes

JURAS

1502




  • Lightweight machine: Working widths even with small tractors
  • High flexibility thanks to hydraulically adjustable working width
  • Durable  FELLA rake head  with enclosed design
HIGH LEVEL OF ADAPTABILITY
The working width is hydraulically infinitely adjustable (from 3.10 m to 7.00 m) and therefore adapts to a wide range of conditions and crop varieties.
PERFECT GROUND ADAPTATION
The cardanic mechanism patented by FELLA in conjunction with the twistable frame and the large-dimensioned tyres ensure perfect ground adaptation. As a result, forage lying in recesses and depressions can be recovered without contamination or loss.
Satz 6 gr2016 2000px
VERY CONVENIENT TRANSPORT
Changing from the working position to the transport position can be conveniently performed from the tractor seat. Also, the tine arms do not have to be removed for road travel. These models have a permissible transport speed of 40 km/h, depending on the country.

Depositing a single swath is just as possible as depositing two small single swaths or a double swath by making a return pass.

Satz 6 gr2016 2000px

















Satz 6 gr2016 2000px














Specifications
Model
JURAS 1502
Category Name
Agriculture
Year
2020
Sale Type
New
Manufacturer
FELLA
PTO Rpm
540 rpm
Rotor Diameter
2960 mm
Weight Approx.
1380 kg
Swath Width Approx.
600-1900 mm
Tine Arms Per Rotor
12/12
Double Tines Per Arm
4
Power Demand Approx.
45 hp
Working Width Approx.
6300 / 7000 mm
Tyres Of Rotor Chassis
2x 18/8.50-8 3x 18/8.50-8
Transport Length Approx.
8450 mm
Transport Width Approx. (mounted Tine Arms)
3000 mm
Transport Width Approx. (dismounted Tine Arms)
2300 mm
