ID # 14128928

Schaffer 2445 SLT

  • Schaffer 2445 SLT
  • Schaffer 2445 SLT
  • Schaffer 2445 SLT
  • Schaffer 2445 SLT
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Wheel loaders

Compact dimensions, perfect manoeuvrability and convincing lifting and traction forces – that is what a Schäffer wheel loader stands for. The machine is very simple and intuitive. The view of the attachments is excellent. The comfortable seating position guarantees relaxed and productive work at all times for the driver – maximum driving fun included.
  Standard equipment
  • Special low construction design
  • Kubota Turbo diesel engine, 4 cylinders, water-cooled, 33 kW (45 HP)
  • Low version front carriage for best lifting force
  • Hydrostatic four wheel drive with automotive control
  • Tyres 10.0/75-15.3 MPT (height 1.98 m)
  • Hydraulic quick gear 20 km/h switchable under load
  • Genuine Schäffer axle
  • Combined oil cooler
  • Multiple disk brake, maintenance free; service and parking brake
  • Maintenance free articulated pendulum joint
  • Restraining system for protection roof
  • 1 x LED working headlight front
  • Parallel lift
  • Working hydraulics: 42 l/min, optional 51 l/min.
  • Stronger gear pump
  • Adjustable steering column
  • Hour meter, fuel control lamp and temperature indicator
  • Counter weight 100 kg mounted under rear chassis
  • Rear weight end plate
  • Tool Box
  • Quick-change frame SWH with hydraulic tool lock
Specifications
Model
2445 SLT
Category Name
Equipment
Year
2018
Sale Type
New
Manufacturer
Schaffer
Diesel Engine
Kubota, 4 cylinders water-cooled
Output
33 kW (45 HP)
Width
1020 mm - 1570 mm
Lifting Capacity
1900 kg
Height Protection Roof
from 1950 mm
Length With Standard Bucket
4200 mm
Lifting Height (tool Pivot)
2500 mm
Working Weight Protection Roof
2480 kg
Turning Radius Inside
1050 mm
Tipping Height (bottom Edge Of Bucket)
1700 mm
Height Cabin
from 1950 mm
Tipping Load Straight, Pallet Fork*
1733 kg - 1954 kg
