Overview
Wheel loaders

Compact dimensions, perfect manoeuvrability and convincing lifting and traction forces – that is what a Schäffer wheel loader stands for. The machine is very simple and intuitive. The view of the attachments is excellent. The comfortable seating position guarantees relaxed and productive work at all times for the driver – maximum driving fun included.
  Standard equipment
  • Kubota Turbo diesel engine, 4 cylinders, water-cooled, 33 kW (45 HP)
  • Low version front carriage for best lifting force
  • Hydrostatic four wheel drive with automotive control
  • Tyres 10.0/75-15.3 MPT
  • Hydraulic quick gear 20 km/h switchable under load
  • Combined oil cooler
  • Multiple disk brake, maintenance free; service and parking brake
  • Maintenance free articulated pendulum joint
  • Restraining system for protection roof
  • #NV
  • Parallel lift
  • Working hydraulics: 42 l/min, optional 51 l/min.
  • Stronger gear pump
  • Adjustable steering column
  • Hour meter, fuel control lamp and temperature indicator
  • Counter weight 100 kg mounted under rear chassis
  • Rear weight end plate
  • Tool Box
  • Quick-change frame SWH with hydraulic tool lock

  HTF
High Traction Force

Automatic thrust regulation, which means that the loader can always deliver the highest level of thrust even at high speed.

Benefits:

  • Even at high speed the maximum thrust is always available, e.g. when driving in muck heaps
  • No need to manually shift down a gear when going up an incline
  • Enhanced driving comfort, faster working
Specifications
Model
2445
Category Name
Equipment
Year
2018
Sale Type
New
Manufacturer
Schaffer
Diesel Engine
Kubota, 4 cylinders water-cooled
Output
33 kW (45 HP)
Width
1020 mm - 1570 mm
Lifting Capacity
1900 kg
Height Protection Roof
2215 mm
Length With Standard Bucket
4045 mm
Lifting Height (tool Pivot)
2500 mm
Working Weight Protection Roof
2450 kg
Turning Radius Inside
1000 mm
Tipping Height (bottom Edge Of Bucket)
1700 mm
Tipping Load Straight, Pallet Fork*
1710 kg - 1912 kg
