Schaffer 2428 SLT

  • Schaffer 2428 SLT
  • Schaffer 2428 SLT
  • Schaffer 2428 SLT
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Wheel loaders
Compact dimensions, perfect manoeuvrability and convincing lifting and traction forces – that is what a Schäffer wheel loader stands for. The machine is very simple and intuitive. The view of the attachments is excellent. The comfortable seating position guarantees relaxed and productive work at all times for the driver – maximum driving fun included.
  Standard equipment
  • Special low construction design
  • Kubota diesel engine, 3 cylinders, water-cooled, 18.5 kW = 25 HP
  • Low version front carriage for best lifting force
  • Hydrostatic four wheel drive with automotive control
  • Tyres 27x8.50-15 SKD incl. reversable rims
  • Genuine Schäffer axle
  • Combined oil cooler
  • Drum brake as service and parking brake
  • Maintenance free articulated pendulum joint
  • Restraining system for protection roof
  • 1 x LED working headlight front
  • Parallel lift
  • Working hydraulics: 33 l/min, optional 42 l/min.
  • Adjustable steering column
  • Hour meter, fuel control lamp and temperature indicator
  • Case weight
  • Rear weight end plate
  • Tool Box
  • Quick-change frame SWH with hydraulic tool lock
Specifications
Model
2428 SLT
Category Name
Equipment
Year
2020
Sale Type
New
Manufacturer
Schaffer
Width
940 mm - 1240 mm
Output
18.5 kW (25 HP)
Diesel Engine
Kubota, 3 cylinders water-cooled
Lifting Capacity
1700 kg
Working Weight Cabin
1960 kg
Turning Radius Inside
850 mm
Height Protection Roof
from 1890 mm
Length With Standard Bucket
3950 mm
Lifting Height (tool Pivot)
2300 mm
Working Weight Protection Roof
1860 kg
Tipping Load Straight, Pallet Fork*
1185 kg - 1311 kg
Tipping Height (bottom Edge Of Bucket)
1450 mm
