ID # 14128762

Schaffer 3550

  • Schaffer 3550
  • Schaffer 3550
  • Schaffer 3550
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Compact loaders

The compact class is one of the most successful series ever built by Schäffer. They have been specifically developed for use in confined spaces. No compromises were, however, made as regards reliability and ergonomics. A wide range of equipment and attachments made the machines extremely versatile.
  Standard equipment
  • Kubota diesel engine, 4 cylinders, water-cooled, 37 kW (50 HP)
  • Hydrostatic four wheel drive with automotive control
  • Tyres 11.5/80-15.3 AS, offset -40
  • HTF (High Traction Force)
  • Hydraulic quick gear 20 km/h switchable under load
  • Genuine Schäffer axle
  • Combined oil cooler
  • Multiple disk brake, maintenance free; service and parking brake
  • Maintenance free articulated pendulum joint
  • Restraining system for protection roof
  • Working headlights on protection roof version: 1 x LED on the boom; cabin version, halogen: 2 x front, 1 x rear
  • Parallel lift
  • Working hydraulics: 46 l/min, optional 52 l/min.
  • Adjustable steering column
  • Hour meter, rev, counter, fuel control lamp and temperature indicator
  • Rear weight end plate
  • Quick-change frame SWH with hydraulic tool lock
Specifications
Model
3550
Category Name
Equipment
Year
2018
Sale Type
New
Manufacturer
Schaffer
Diesel Engine
Kubota diesel engine, 4 cylinders, water-cooled
Output
37 kW (50 HP)
Width
1020 mm - 1720 mm
Lifting Capacity
2000 kg
Height Protection Roof
2270 mm
Length With Standard Bucket
4185 mm
Lifting Height (tool Pivot)
2950 mm / 3200 mm**
Working Weight Protection Roof
2800 kg
Turning Radius Inside
1100 mm
**Option
high lift version
Tipping Height (bottom Edge Of Bucket)
2140 mm / 2390 mm**
Height Cabin
2230 mm
