Overview
Compact loaders
The compact class is one of the most successful series ever built by Schäffer. They have been specifically developed for use in confined spaces. No compromises were, however, made as regards reliability and ergonomics. A wide range of equipment and attachments made the machines extremely versatile.
  Standard equipment
  • Electric motor driving hydraulics: 21 kW; electric motor working hydraulics: 9,7 kW
  • Electric four wheel drive with cardan shaft
  • On board charging device 3 kW / 230 V / 16 A
  • Battery management system
  • Energy recuperation
  • Hill-Hold funktion: ’start up assistant’ to make hill starts easier
  • Tyres 10.0/75-15.3 AS, offset +40
  • 20 km/h
  • Eco mode to extend the operating time
  • Genuine Schäffer axle
  • Water cooling of electric motors
  • Multiple disk brake, maintenance free; service and parking brake
  • Maintenance free articulated pendulum joint
  • Restraining system for protection roof
  • 1 x LED working headlight front
  • Acoustic reverse warning signal
  • Parallel lift
  • Electronically operated additional controller
  • Working hydraulics: 42 l/min
  • Adjustable steering column
  • Hour meter, range display and charging status display
  • Rear weight end plate
  • Main battery switch
  • Quick-change frame SWH with hydraulic tool lock
Specifications
Model
23e
Category Name
Equipment
Year
2020
Sale Type
New
Manufacturer
Schaffer
Width
1020 mm - 1570 mm
**Option
high lift version
Lifting Capacity
1700 kg
Turning Radius Inside
835 mm
Height Protection Roof
from 2215 mm
Length With Standard Bucket
3880 mm
Lifting Height (tool Pivot)
2880 mm / 3110 mm**
Working Weight Protection Roof
2300 kg
Electric Engine Driving Hydraulics
21 kW
