ID # 13655520

Gravely Atlas JSV®3000

  • Gravely Atlas JSV®3000
  • Gravely Atlas JSV®3000
  • Gravely Atlas JSV®3000
  • Gravely Atlas JSV®3000
  • Gravely Atlas JSV®3000
  • Gravely Atlas JSV®3000
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
​With class-leading towing capacity and heavy-duty suspension, the Atlas JSV®​ is dedicated to getting the job done with a level of power and performance to make any crew proud. Haul, tow, work, dump—this ultimate job site vehicle seats three, or six, comfortably.
   Features

https://www.gravely.com/assets/images/products/Features/Pro-Turn-200-Seat.jpg

Class Leading Capacity

https://www.gravely.com/assets/images/products/Features/Pro-Turn-200-Seat.jpg

All-Steel Job Box

https://www.gravely.com/assets/images/products/Features/Pro-Turn-200-Seat.jpg

de Dion Suspension
Total Payload
With a class-leading bed capacity of 1250 lbs and 1900-lb total payload, the Atlas JSV holds its own
Job Box
The Atlas JSV's fabricated all-steel cargo bed won't buckle or bend. Dump cargo with the touch of a button and haul a fully loaded pallet thanks for a generous 18 cubic feet of cargo space
Suspension
Our heavy-duty de Dion suspension minimizes sag, to maintain full ground clearance even with cargo, tongue weight and towing maxed out
Tow A Ton

Tow A Ton

The Atlas JSV can tow a ton. Literally. Hitch up a full 2000-lbs of trailer and cargo and get more done in less time
Pick Your Power

Pick Your Power

Choose the 3-cylinder, 1028cc KOHLER® Diesel engine to maximize torque, or run with an electronically fuel-injected DOHC gasoline engine
Seat Up To 6

Seat Up To 6

The Atlas JSV-3000 seats three adults comfortably. The crew-size JSV-6000 seats 6 adults across two benches, with a total payload of 2100 lbs
  Specifications


Model Engine Manufacturer Engine Rating Fuel System Length Peak Alternator Output Seat Belts Seating Total Rated Payload Weight Wheel Base
996200 Polaris® 40 HP/570 CC EFI 128" (325 cm) 45A 3 3-point 3 1900 lb 1575 lb 84" (213 cm)
996201 Polaris® 40 HP/570 CC EFI 165" (419 cm) 45A 6 3-point 6 2100 lb 1800 lb 116" (294.6 cm)
996202 Kohler® 24HP/1028CC Indirect Injection 128" (325 cm) 110A 3 3-point 3 1900 lbs 1675 lb 84" (213 cm)
996203 Kohler® 24HP/1028CC Indirect Injection 165" (419 cm) 110A 6 3-point 6 2100 lb 1900 lb 116" (294.6 cm)



Specifications
Model
Atlas JSV®3000
Category Name
Utility Vehicle Attachments
Year
2017
Sale Type
New
Manufacturer
Gravely
