Engine: 4-Stroke, SOHC, Single, Air/Oil Cooler w/ Fan - Displacement: 348 cc - Bore and Stroke: 83mm x 64.5mm - Compression Ratio: 9.20:1 - Carburetion: Mikuni BSR33 - Ignition: DC - CDI - Starting: Electric w/ Recoil Backup - Lubrication: wet sump - Oil Capacity: 3.10 L - Transmission: Yamaha Ultramatic V-Belt / F,N,R - Final Drive: On-command push button 2WD / 4WD / 4WD diff. lock, shaft drive - Suspension (Front): Double Wishbone - Suspension (Rear): Double Wishbone - Brakes (Front): Dual Disc - Brakes (Rear): Fully Sealed , Oil Bath, Multi Disc - Tires (Front): AT25x8-12 - Tires (Rear): AT25x10-12 - Length: 1,995 mm (78.5") - Width: 1,095 mm (43.1") - Height: 1,120 mm (44.1") - Wheelbase: 1,235 mm (48.6") - Ground Clearance: 245 mm (9.6") - Seat Height: 830 mm (32.7") - Dry Weight: 262.4 kg (578 lb) - Wet Weight: 275 kg (606 lb) - ready to ride full of fuel and oil - Fuel Capacity: 13.5 litres - Towing Capacity: 500 kg (1,100 lb)
