Weidemann articulated pendulum joint

The backbone of the Weidemann design. The legendary articulated pendulum joint. All four wheels remain in constant contact with the ground and the machine moves with maximum traction. In addition, the machine has unrivalled manoeuvrability.

High quality powder coating

Quality creates added value. The powder coating is a key feature of the Weidemann quality standard. In contrast to the conventional wet painting, it greatly increases the service life and is more efficient and also environmentally friendly in the process.

High shear forces from planetary axle

The drive via the planetary axle increases the torque on the wheel and thereby improves the shear force. Due to the optimal ratio between the shear force and machine capacity, you work flexibly and economically at the same time.

100% differential lock

If necessary, the up to 100% connectable differential lock offers you maximum traction and shear force and keeps the tyre wear low (switched off during normal operation).

Two strong lift cylinders

Weidemann always installs two lift cylinders in all Hoftrac and wheel loader models. This guarantees that the load distribution is always optimally transferred to the loading arm. In addition, the entire loading system gains stability. The size of the lift cylinder is adapted to the respective size of the machine.

Perfectly matched Z-kinematics

The angled loading arm is designed to be particularly sturdy and torsion resistant. At Weidemann, the kinematics are adjusted to the size of the machine: this ensures optimal balances of power for every machine. The Z-kinematics ensure that the force will always be utilised optimally when loading and unloading the bucket. In doing so, the Z-kinematics generate tremendous lifting and shearing forces in quick cycles.

Stainless steel steering stops

At a full steering stop, the front and rear carriage of the machine touch. With Weidemann, this area is particularly well-protected by the stainless steel steering stops and the machine’s paint is not damaged. This provides for value preservation!

Large selection of attachment tools

Use your machine as a multi-tool: you have a wide selection of attachments available for your Weidemann.

Large selection of tyres

The optimal tyres for every subgrade: you have a wide selection of different tyres available for your Weidemann.
