Unverferth Equipment Seed Conveyors

  • Unverferth Equipment Seed Conveyors
  • Unverferth Equipment Seed Conveyors
  • Unverferth Equipment Seed Conveyors
  • Unverferth Equipment Seed Conveyors
  • Unverferth Equipment Seed Conveyors
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Unverferth Bulk Handling

It’s belt capacity, not speed that makes moving seed with an Unverferth pull-type tubular-style conveyor both fast and gentle. The 2” vulcanized cleats are spaced 6” apart on the 12” PVC belt inside of an 8" tube for carrying large volumes of seed at low operating speed for minimal seed damage.

Unverferth 8" portable seed conveyors can move up to 34 bushels per minute (2,040 bushels per hour) and are constructed of tubular-steel with powder-coat finish for optimum durability. They feature a heavy-duty steel transport frame, new implement tires and a wide, 8-foot base for extra stability when in a high working position and during towing. Operating height is easily adjusted with a friction-disc winch.
  Features
  • Conveyor features field-proven 2” vulcanized cleats spaced 6” apart, providing high-capacity movement at lower speeds for the most gentle seed handling.
  • Hoppers are extra wide for unloading convenience and feature a lower hinged cleanout door for easily removing leftover seed and a protective grating over the intake for enhanced operator safety
  • The hopper design is ideal for unloading bulk seed bags yet versatile enough to also work easily with wagons and bins
  • The hitch features tool-free installation for moving the conveyor from one farm to the next and can be equipped with an optional transport chain for safer transport on roadways
  • Equipped with your choice of orbital hydraulic or electric motor (single or three-phase)
  • Hydraulic operating speed of 350 r.p.m. with 21' model and 230 r.p.m. with 30' and 35' models for the gentlest seed handling
  • Convenient dual lever controls for easily controlling the speed of the hydraulic motor
  • Models are available in 8" x 21', 8" x 30' and 8" x 35' sizes
Specifications
Model 8" x 21' 8" x 30' 8" x 35'

Due to continuing improvements in the design and manufacture of Unverferth seed conveyors, all specifications contained herein are subject to change without notice.
Transport Height 10' 10'1" 11'9"
Transport Length 24'11" 35' 39'10"
Maximum Discharge Height 13' 21'9" 24'3"
Minimum Discharge Height 8'3" 6'11" 9'4"
Maximum Overall Height 15'6" 24'8" 26'10"
Minimum Overall Height 10'9" 11'5" 12'
Reach - Maximum Height 3'4" 5'6" 10'3"
Reach - Minimum Height 5'5" 11'3" 14'
Average Capacity @ 30° Angle 2,040 bph 2,040 bph 2,040 bph
Approx. Weight (lbs.) 975 2,246 2,325





Specifications
Model
Seed Conveyors
Category Name
Agriculture
Year
2015
Sale Type
New
Manufacturer
Unvenferth
