The AerWay® family of patented vertical tillage tines are designed to relieve compaction, manage crop residue, and warm the loosened soil for seedbed preparation. The patented tine technology is available in both ShatterTine® and Leaf Tine® profiles.
AerWay vertical tillage is accomplished by the unique lean and twist of the tines designed to move soil laterally, plus lift and fracture soils to 8 inches and deeper. New pathways are created for air and water movement, while maintaining the valuable protective surface residue. With better soil conditions, plants respond with stronger roots and better yields.
Features
Features:
Frame Configuration – Available in 10 to 40-ft. widths. Single roller system with four tines per row. Standard 7 ½” tine spacing. Patented CCT (Close Coupled Tandem) uses two overlapping tined rollers, with three tines per row, giving you more pockets and fractures per acre.
Wing Down Pressure Valve – Standard on all Folding Wing models. Valve is pre-set at the factory but can be easily adjusted in the field to suit varying ground conditions.
Trunnion Bearing & Mounting Bracket – Heavy-duty 50mm bearing standard on all AWST and AWFT machines. No-lube bearings are designed for severe service applications.
C-Flex System – Standard on all AWST and AWFT machines. Designed to protect rollers from impact and shock loads.
Options:
Rolling Baskets – Available with either 3-Bar Coil Tines with 14” Single Roller or a Double Row 14” Harrow Basket.
Rear Tool Bar – AWST and AWFT frames are designed to accept an optional rear tool bar, allowing the user to attach his own finishing tools.
Pull-type Wheel Kits – Designed to convert the machinery into a “trail” unit with tires rearward.
Scraper System for Rollers – For units working in challenging or high-residue conditions.
Ballast Blocks – For hard compacted ground conditions, ballast blocks are available in 550 and 750-lb. weights.
Lighting Kit – Includes two lights and two universal mounting brackets and harnesses.
Benefits:
Versatility – Quick-adjust feature allows you to easily vary the roller swing angle to meet your tillage and cropping demands.
Value – Can be used full season and is readily adaptable to no-till, minimum till, and conventional till practices.
All-Season – Ideal in the springtime for warming and drying soils. Post-harvest use allows your soils to breathe and promotes better residue breakdown.
Dependable – All components chosen for strength and durability to withstand the demands of day-to-day farming.
Outstanding Yields – Get top yields with lower input costs. It all comes down to the bottom line.
Specifications
AWST FRAME CONFIGURATIONS - Straight Frame
CCT AerWay ® – available in 3.75” (0.10 m)
Model Number
Cultivation Width
Travel Width
# of Tines 3.75” (0.10 m)
Weight
HP Required
AWST100-CCT
10’ (3.05 m)
10’ (3.05 m)
96
3174 lbs (1.44 T)
90-150
AWST125-CCT
12.5’ (3.81 m)
12.5’ (3.81 m)
120
3749 lbs (1.70 T)
115-190
AWST150-CCT
15’ (4.57 m)
15’ (4.57 m)
144
4324 lbs (1.96 T)
135-225
AWST200-CCT
20’ (6.10 m)
20’ (6.10 m)
192
6048 lbs (2.74 T)
180-300
AWFT FRAME CONFIGURATIONS - Folding Frame
CCT AerWay ® – available in 3.75” (0.10 m) effective tine spacing
