Princecraft
ID # 18523972
Princecraft Vogue® 23 XT
Call for Price
Overview
Specifications
general specifications
manufacturer's recommendations (canada)
gas tank
features
construction features
helm
instrumentation
furniture
tops
other standard features
factory installed options
dealer installed options
dealer installed options (canvas)
colors
mercury outboard engine
optional trailer(s)
trailer options
Videos
|
This 23’-11’’ pontoon features all the comfort and convenience you enjoy at home… and more. Automative-style raised helm console including a SIMRAD Go7 multifunction touchscreen with VesselView Link allowing instrumentation display, GPS functions, and sonar (that replaces the standard gauges) and a wireless smartphone charger; cup holder modules and USB ports integrated into the padding; 4 chaise lounges; integrated trash storage compartment; folding table with cup holders; oversized stern swim platform and boarding ladder. Have a party with up to 10 friends or enjoy your favorite water sports in the greatest luxury. Rig your pontoon with an engine up to 250 HP (with the optional Performance Configuration) and get ready for some serious fun! |
Model
VOGUE 23 XT
Category Name
Boat
Year
2022
Sale Type
New
Manufacturer
Princecraft
Color
Metallic Black / Metallic Blue / Titanium / Ruby Red
Beam
2.6 m (8'-6")
Deck Length
7.2 m (23'-6")
Overall Length
7.3 m (23'-11")
Pontoon Length
6.8 m (22'-4")
Pontoon Diameter
0.64 m (25")
Approximate Weight
1060 kg (2337 lb.) / 1173 kg (2667 lb.) with Sport config. / 1310 kg (2889 lb.) with Performance config.
Pontoon Aluminum Thickness
2.0 mm (.080")
Maximum HP Capacity
112 kW (150 HP)
Maximum Person Capacity
10
Maximum Weight Capacity
935 kg (2062 lb.)
Maximum Weight Person Capacity
635 kg (1400 lb.)
Built-in
110 L (29 U.S. gal.)
Features
|
Optional stainless steel waterski tow bar |
|
Wireless smart phone charger integrated to the console |
|
Driver console (shown with the optional Premium High Power Stereo System, including a Simrad Go9 touchscreen - right screen) |
|
Loungers cup holders with USB port in upholstery |
|
LED docking lights |
|
Black folding pedestal mount removable table with cup holders |
|
Simrad standard touch screen |
|
Large stern telescopic stainless steel ladder |
|
4 stainless steel recessed cleats |
|
Trash storage integrated into the back of the chaise lounge |
CONSTRUCTION FEATURES
- 5052-H36 marine grade aluminum alloy
- NMMA & Transport Canada certified
- 2 ½" heavy-duty extruded Z-aluminum cross channels
- APS style side panels
- Sealed pontoon bulkheads with top mounted air plug (25")
- V-shaped aluminum engine pod
- Pressure-treated wood deck covered with marine grade carpet
- Extruded aluminum full-length pontoon keels
- Extruded aluminum full-length pontoon skirting
- Stern molded corners
- Walk-thru rear gate with lift and lock hinges
- Walk-thru bow gate with lift and lock hinges
- Port side gate with lift and lock hinges (20'')
- Extra large stern swim platform
- Bow fiberglass molded section with integrated LED lighting
- Stainless steel bow eye
- 4 stainless steel recessed cleats
- Permanent gas tank of 110 L / 29 U.S. gal.
Helm
- Automative style raised fiberglass helm
- Padded footrest with Princecraft logo
- Molded dash panel with black inserts and lighted switches
- Sport tilt steering mechanism
- AM/FM/Bluetooth KMC100 Kicker Stereo with integrated USB plug and auxiliary input (1/8") in console
- 4 waterproof speakers
- Electric horn
- 12V outlet
- Wireless smartphone charger integrated to the console
- Push on/off console courtesy light
- LED lighting under driver console
- Quick release smoked windscreen
INSTRUMENTATION
- SIMRAD Go7 multifunction touch screen with VesselView Link allowing instrumentation display, GPS functions and sonar
FURNITURE
- Ultra plush and heavy weight upholstery
- Roto-Cast furniture bases and backs
- Loungers cup holders with USB port
- Removable bow gate seat
- Reclining captain's chair on slide and swivel
- Passenger captain seat on slide and swivel
- 4 chaise lounges
- Storage in chaise lounges' reclined section
- Integrated trash storage
- 3 storage pouches
- Storage under all lounges
- Pop-up privacy enclosure
- Black folding pedestal mount snack table with cup holders
Tops
- High-end black bimini top with chrome finish structure
- Quick release bimini top latches and traveling struts
- Factory installed snap fasteners for canvas camper enclosures & mooring/trailer top options
OTHER STANDARD FEATURES
- Large stern telescopic stainless steel boarding ladder
- Cup holders
- Bow chromed corner light housings
- LED docking lights
- Navigation lights
- LED floor mood lighting
- Chrome finish 3D logo
- Transducer mounting brackets
- Standard stainless steel propeller (on 175 HP engines and up)
- Battery box
Colors
- Metallic Black
- Metallic Blue
- Titanium
- Ruby Red
MERCURY OUTBOARD ENGINE
- Mercury 40 ELPT CT
- Mercury 60 ELPT CT
- Mercury 90 EXLPT CT
- Mercury 115 EXLPT CT
- Mercury 115 EXLPT PRO XS CT
OPTIONAL TRAILER(S)
- 6922042-GALVANIZED TANDEM AXLE SCISSOR-LIFT STYLE TRAILER WITH BRAKES (FOR 2 LOGS ONLY)
- Sealed hubs, swivel tongue jack and 2" ball coupler
- Drum brakes (on all axles)
- Factory balanced wheels
- Tire size : 5.30 X 12'' C
- Weight : 293 kg (645 lb.)
- 1607 kg (3535 lb.) carrying capacity
- 6934042-GALVANIZED TANDEM AXLE BUNK SUPPORT STYLE TRAILER WITH BRAKES (2 logs; for 3-log pontoons, the trailer must be equipped with the optional Conversion kit for 3-log models)
- Carpeted fixed bunks
- Sealed hubs, swivel tongue jack and 2" ball coupler
- Drum brakes (on all axles)
- Factory-balanced wheels
- LED lights
- Tire size: 20.5 x 8 x 10'' C
- Weight : 439 kg (966 lb.)
- 1571 kg (3456 lb.) carrying capacity
- 6935042-GALVANIZED TANDEM AXLE BUNK SUPPORT STYLE TRAILER WITH DISC BRAKES (2 logs; for 3-log pontoons, the trailer must be equipped with the optional Conversion kit for 3-log models)
- Carpeted fixed bunks
- Sealed hubs, swivel tongue jack and 2" ball coupler
- Disc brakes (on all axles)
- Factory-balanced wheels
- LED lights
- Tire size: ST175/80R13C
- Weight : 460 kg (1012 lb.)
- 2013 kg (4429 lb.) carrying capacity
- 6935082-GALVANIZED TRIDEM AXLE BUNK SUPPORT STYLE TRAILER WITH DISC BRAKES (2 logs; for 3-log pontoons, the trailer must be equipped with the optional Conversion kit for 3-log models)
- Carpeted fixed bunks
- Sealed hubs, swivel tongue jack and 2" ball coupler
- Disc brakes (on all axles)
- Factory-balanced wheels
- LED lights
- Tire size: ST175/80R13C
- Weight : 530 kg (1168 lb.)
- 3178 kg (6991 lb.) carrying capacity
Videos
Model
VOGUE 23 XT
Category Name
Boat
Year
2022
Sale Type
New
Manufacturer
Princecraft
Quantity
0
Color
Metallic Black / Metallic Blue / Titanium / Ruby Red
