Princecraft aluminum deck boats are designed for water sports, sport fishing, and relaxing on the water with friends and family. All you have to do is choose the particular model, features, and configuration that meet your needs! |
|
SPECIFICATIONS GENERAL SPECIFICATIONS
Center line : 5.8 m (19'-2")
Beam : 2.5 m (97")
Bottom width : 2.1 m (83")
Maximum depth : 0.8 m (32")
Approximate draft : 0.7 m (29")
Transom height : 0.64 m (25")
Approx. weight : 847 kg (1868 lb.) |
|
TRANSPORTS CANADA
Max. HP cap. : 112 kW (150 HP)
Max. weight cap. : 938 kg (2067 lb.)
Maximum person capacity : 8
Maximum weight person capacity : 600 kg (1323 lb.) |
|
NMMA (USA)
Max. HP cap. : 112 kW (150 HP)
Max. weight cap. : 946 kg (2085 lb.)
Maximum person capacity : 10
Maximum weight person capacity : 600 kg (1323 lb.) |
|
ALUMINUM THICKNESS
Bottom : 2.8 mm (.110")
Side : 2.8 mm (.110") |
|
BUILT-IN GAS TANK
Permanent : 189 L (50 U.S. gal.) |
|
FEATURES
CONSTRUCTION FEATURES
5052-H36 marine grade aluminum alloy
NMMA & Transport Canada certified
Pressure treated wood deck covered w/ marine grade carpet (20 oz)
High-gloss exterior oven-cured High Solids Urethane paint
High performance deep Vee reverse chine hull design
Stainless steel bow eye
6 stainless steel cleats (6")
Side panel rigging tubes from stern to console and console to bow
Rear boarding access w/ gates
Full-width rear padded sun deck
Built-in floor cooler
In-floor lockable ski storage compartment
Anchor storage |
|
HELM
Fiberglass helm console with glove box
Thermoformed Laser Wave dash panel w/ lighted switches
No-FeedBack dual cable steering system
Electric horn
160-watt AM/FM/Bluetooth Jensen Stereo with integrated auxiliary input in console
4 waterproof speakers
12V outlet
Quick release smoked windscreen
Switches w/ breaker system protection |
|
INSTRUMENTATION
Digital throttle and shift system (DTS) - with Verado engine only
Tachometer, voltmeter, spedometer, trim and fuel gauges |
|
SEATS
Roto-Cast bucket seat captain's chair on slide and swivel |
|
FURNITURE
Plush and heavy weight upholstery
2 chaises lounge
Storage under all lounges
Pedestal mount stern removable snack table w/ drink holders |
|
TOPS
Color coordinated deluxe convertible buggy bimini top
Quick release bimini top latches and traveling struts
Canvas camper enclosure & mooring cover snap fasteners |
|
OTHER FEATURES
Stern boarding ladder
Built-in floor fuel system
2 electric bilge pumps (500 gph)
1 battery tray
Navigation lights
Interior lighting
Cup holders
Holding handle |
|
OPTIONS FACTORY INSTALLED OPTIONS
Premium High Power/Sub Audio System…upgrade exchange
200-watt AM/FM/Bluetooth Clarion Stereo compatible SAT with integrated USB plug and auxiliary input in console
SmartCraft gauges (tachometer, speedometer and trim)...upgrade exchange
Sea Star hydraulic steering system w/ tilt wheel…upgrade exchange
Wakeboard towing tower package with anodized aluminum towing tower
Starboard side swim platform with stainless steel boarding ladder…upgrade exchange
Port and starboard side swim platform with stainless steel boarding ladder…upgrade exchange
Flush mount halogen docking lights
Tilt steering mechanism…upgrade exchange
Bolster captain's chair…upgrade exchange
Chemical toilet w/ holding tank and pump out (9.8 L / 2.6 U.S. gal.)
Underwater lighting (2 lights) |
|
DEALER INSTALLED OPTIONS (CANVAS)
Mooring cover
Trailer cover
Full camper enclosure
Half (1/2) camper enclosure w/ front cockpit cover
Double bimini top |
|
COLORS
Black with Mocha Cut Loop carpet (20 oz.)
Brite Blue with Cut Loop Mocha carpet (20 oz.)
Regal Red with Mocha Cut Loop carpet (20 oz.) |
|
MERCURY OUTBOARD ENGINE OPTIONS
Mercury 90 EXLPT 4S
Mercury 115 EXLPT 4S
Mercury 150 XL 4S
Mercury 150 XL Verado L4 |
|
OPTIONAL TRAILER(S)
CUSTOM BLACK OR GALVANIZED BUNK STYLE TRAILER, WITH DISC BRAKES AND SWING TONGUE
Single axle w/ disc brakes & swing tongue
Carpeted fixed bunks, step pads and load guide
Checker polished aluminum covered step pads
Bearing protectors, swivel tongue jack and 2" ball coupler
1 551 kg (3 420 lb.) carrying capacity
Factory balanced steel wheels
Radial tire size : ST205/75R14 C
Weight : 400 kg (880 lb.) |
|
TRAILER OPTIONS
Deluxe transom tie downs…/pair
Transom saver motor support bar
Spare wheel ST205/75R14 C, 5 lugs…galvanized
Spare wheel ST205/75R14 C, 5 lugs…painted
2-14" aluminum mag wheels (14") with cap and nuts…upgrade exchange on painted trailer
2-14" aluminum mag wheels (14") with cap and nuts…upgrade exchange on galvanized trailer
14" aluminum mag wheel…(excluding cap and nuts) |
