Hisun PArts

Parts
No
Old Part No
New Part No
Description
Price
QTY
0
P0070001207A0000
P0070001207A0000
Gasket,Cylinder Head
0
1
1
PJ00000908020400
PJ00000908020400
Pin,Dowel 12×16
0
2
2
P007000120110000
P007000120110000
Cylinder Bolts M9×38.5
0
2
3
PJ00000906003400
PJ00000906003400
Washer 10×19×2
0
6
4
P0160001211A0000
P0160001211A0000
Cylinder Body Assembly
0
1
5
PJ00000912019500
PJ00000912019500
O-Ring 105.7×2.8
0
1
6
P007000120090000
P007000120090000
Gasket,Cylinder Base
0
1
7
P016000110120000
P016000110120000
Bolts For Cylinder M10×1.25×121
0
2
8
P016000110180000
P016000110180000
Bolts For Cylinder M10×1.25×128
0
2
9
P004000110070000
P004000110070000
Pipe Clamp ?
0
1
10
BGB70M640
BGB70M640
Hexagon Socket Head Cap Screws M6×40
0
2
11
PJ00000908020600
PJ00000908020600
Pin,Dowel 14×16
0
2
12
P007000145080000
P007000145080000
Gasket,Tensioner
0
1
13
P007000145300000
P007000145300000
Tensioner Assy.
0
1
14
BGB70M625
BGB70M625
Hexagon Socket Head Cap Screws M6×25
0
2
Overview

Gasket,Cylinder Head .

Gasket,Cylinder Head of #:Engine - CYLINDER

Pin,Dowel 12×16 .

Pin,Dowel 12×16 of #:Engine - CYLINDER

Cylinder Bolts M9×38.5 .

Cylinder Bolts M9×38.5 of #:Engine - CYLINDER

Washer 10×19×2 .

Washer 10×19×2 of #:Engine - CYLINDER HEAD

Cylinder Body Assembly .

Cylinder Body Assembly of #:Engine - CYLINDER

O-Ring 105.7×2.8 .

O-Ring 105.7×2.8 of #:Engine - CYLINDER

Gasket,Cylinder Base .

Gasket,Cylinder Base of #:Engine - CYLINDER

Bolts For Cylinder M10×1.25×121 .

Bolts For Cylinder M10×1.25×121 of #:Engine - CYLINDER

Bolts For Cylinder M10×1.25×128 .

Bolts For Cylinder M10×1.25×128 of #:Engine - CYLINDER

Pipe Clamp ? .

Pipe Clamp Ⅱ of #:Engine - Cylinder

Hexagon Socket Head Cap Screws M6×40 .

Hexagon Socket Head Cap Screws M6×40 of #:Engine - CYLINDER HEAD

Pin,Dowel 14×16 .

Pin,Dowel 14×16 of #:Engine - Cylinder

Gasket,Tensioner .

Gasket,Tensioner of #:Engine - CYLINDER

Tensioner Assy. .

Tensioner Assy. of #:Engine - CYLINDER

Hexagon Socket Head Cap Screws M6×25 .

Hexagon Socket Head Cap Screws M6×25 of #:Engine - Cylinder Head Components
