Hisun PArts

Parts
No
Old Part No
New Part No
Description
Price
QTY
0
P0040002114A0150
P0040002114A0150
Hub Assy,Clutch
0
1
1
P0040002111A0150
P0040002111A0150
Friction shoes assembly,Clutch
0
1
2
P0040002113A0000
P0040002113A0000
Clutch One Way Bearing Assy
0
1
3
PJ00000904021401
PJ00000904021401
Hexagon Flange Nut M221
0
1
4
P0040002116A0100
P0040002116A0100
Primary Disc Assy
0
1
5
BGB894152
BGB894152
Circlip For Shaft ?52
0
1
6
PJ00000906001700
PJ00000906001700
Washer 19.2353.2
0
1
7
PJ00000904020700
PJ00000904020700
Hexagon Flange Nut M161
0
2
8
P004000213000000
P004000213000000
Cvt Belt
0
1
9
P004000212000000
P004000212000000
Secondary Sheave Assy
0
1
Overview

Hub Assy,Clutch .

Hub Assy,Clutch of #:Engine - Clutch Assembly

Friction Shoes Assembly,Clutch .

Friction shoes assembly,Clutch of #:Engine - Clutch Assembly

Clutch One Way Bearing Assy .

Clutch One Way Bearing Assy of #:Engine - Clutch

Hexagon Flange Nut M221 .

Hexagon Flange Nut M221 of #:Engine - Clutch Assembly

Primary Disc Assy .

Primary Disc Assy of #:Engine - Clutch Assembly

Circlip For Shaft ?52 .

Circlip For Shaft ∅52 of #:Engine - Clutch Assembly

Washer 19.2353.2 .

Washer 19.2353.2 of #:Engine - Clutch Assembly

Hexagon Flange Nut M161 .

Hexagon Flange Nut M161 of #:Engine - Clutch Assembly

Cvt Belt .

Cvt Belt of #:Engine - Clutch

Secondary Sheave Assy .

Secondary Sheave Assy of #:Engine - Clutch
