Hisun PArts

Parts
No
Old Part No
New Part No
Description
Price
QTY
0
P311001611000000
P311001611000000
Steering Wheel Assy
0
1
1
P311001611200000
P311001611200000
Fixed Cap, Steering Wheel
0
1
2
BGB701M520B
BGB701M520B
Socket Hexagon Screw M520
0
6
3
P311001346110000
P311001346110000
Insulation Spacer For Horn 1
0
1
4
P311001346180000
P311001346180000
Horn Switch
0
1
5
P311001823050000
P311001823050000
Steering Column Cover ?
0
1
6
P112D00641000000
P112D00641000000
Steering Gear Assy
0
1
7
BGB27660032RZ
BGB27660032RZ
Deep Groove Ball Bearing 60032Rz
0
1
8
P311001612200000
P311001612200000
Adjustable Steering Wheel Swivel
0
1
9
BGB2766805
BGB2766805
Deep Groove Ball Bearing 6805
0
1
10
P315001372000000
P315001372000000
Ignition Switch Assy
0
1
11
P311001346130000
P311001346130000
Ground Lead For Horn
0
1
12
P311001612300000
P311001612300000
Gas Spring
0
1
13
PJ00000929710100
PJ00000929710100
Grooved Pin ?834
0
1
14
BGB8965
BGB8965
Circlip ?5
0
2
15
P311001612100000
P311001612100000
Adjustable Steering Wheel Base
0
1
16
BGB16674M1012516
BGB16674M1012516
Hexagon Flange Bolt M1012516
0
3
17
PJ00000902160000
PJ00000902160000
Inner Hexagon Cone Bolt M6?1025305
0
2
18
BGB6187M6
BGB6187M6
Hexagon Flange Locked Nut M6
0
2
19
PJ00000929710200
PJ00000929710200
Grooved Pin ?845
0
1
22
PJ00000902250000
PJ00000902250000
Socket Hexagon Screw M612
0
2
23
BGB845ST3925BA
BGB845ST3925BA
Cross Small Plate Head Tapping Screw ST3913
0
3
24
P303001621300000
P303001621300000
Direction Driveshaft Assy
0
1
25
BGB16674M830
BGB16674M830
Hexagon Flange Bolt M830
0
1
26
P311001642100000
P311001642100000
Steering Gear Ball Joint 12mm
0
2
27
P311001642100000
P311001642100000
Steering Gear Ball Joint 14mm
0
0
28
BGB9459M12125
BGB9459M12125
Hexagon Nut M12
0
2
29
BGB91230
BGB91230
Cotter Pin 230
0
2
30
PJ00000903480200
PJ00000903480200
Hexagon Flange Bolt & Spring Washer & Plain Washer M1035
0
4
31
PJ00000906000700
PJ00000906000700
Washer 10325
0
3
32
BGB9310
BGB9310
Spring Washer ?10
0
3
33
BGB938
BGB938
Spring Washer 8
0
1
34
BGB9718
BGB9718
Plain washer 8
0
1
35
P311001346120000
P311001346120000
Insulation Spacer For Horn 2
0
1
36
P311001611300000
P311001611300000
Adapter Sleeve, Steering Wheel
0
1
37
P311001346150000
P311001346150000
Connection Strap For Horn
0
1
38
P311001346170000
P311001346170000
Horn Spring
0
1
39
BGB818M48
BGB818M48
Cross Recessed Plate Head Screw M48
0
1
40
BGB6187M12125
BGB6187M12125
Hexagon Flange Lock Nut M12125
0
1
41
BGB8941d0=17
BGB8941d0=17
Circlip D0=17
0
1
42
PJ00000907100700
PJ00000907100700
Elastic Hoop H
0
2
43
P115000641060000
P115000641060000
Clamp
0
2
44
P115000641030000
P115000641030000
Rubber Boot I
0
2
45
BGB6170M14125
BGB6170M14125
Hexagon Nut M14125
0
2
46
P115000642000000
P115000642000000
Ball Joint Assy
0
2
Overview

Steering Wheel Assy .

Steering Wheel Assy of #:Steering - Steering

Fixed Cap, Steering Wheel .

Fixed Cap, Steering Wheel of #:Steering - Steering

Socket Hexagon Screw M520 .

Socket Hexagon Screw M520 of #:Steering - Steering

Insulation Spacer For Horn 1 .

Insulation Spacer For Horn 1 of #:Steering - Steering

Horn Switch .

Horn Switch of #:Steering - Steering

Steering Column Cover ? .

Steering Column Cover Ⅰ of #:Steering - Steering

Steering Gear Assy .

Steering Gear Assy of #:Steering - Steering

Deep Groove Ball Bearing 60032Rz .

Deep Groove Ball Bearing 60032Rz of #:Steering - Steering

Adjustable Steering Wheel Swivel .

Adjustable Steering Wheel Swivel of #:Steering - Steering

Deep Groove Ball Bearing 6805 .

Deep Groove Ball Bearing 6805 of #:Steering - Steering

Ignition Switch Assy .

Ignition Switch Assy of #:Steering - Steering

Ground Lead For Horn .

Ground Lead For Horn of #:Steering - Steering

Gas Spring .

Gas Spring of #:Steering - Steering

Grooved Pin ?834 .

Grooved Pin Φ834 of #:Steering - Steering

Circlip ?5 .

Circlip Φ5 of #:Steering - Steering

Adjustable Steering Wheel Base .

Adjustable Steering Wheel Base of #:Steering - Steering

Hexagon Flange Bolt M1012516 .

Hexagon Flange Bolt M1012516 of #:Steering - Steering

Inner Hexagon Cone Bolt M6?1025305 .

Inner Hexagon Cone Bolt M6Φ1025305 of #:Steering - Steering

Hexagon Flange Locked Nut M6 .

Hexagon Flange Locked Nut M6 of #:Steering - Steering

Grooved Pin ?845 .

Grooved Pin Φ845 of #:Steering - Steering

Socket Hexagon Screw M612 .

Socket Hexagon Screw M612 of #:Steering - Steering

Cross Small Plate Head Tapping Screw ST3913 .

Cross Small Plate Head Tapping Screw ST3913 of #:Steering - Steering

Direction Driveshaft Assy .

Direction Driveshaft Assy of #:Steering - Steering

Hexagon Flange Bolt M830 .

Hexagon Flange Bolt M830 of #:Steering - Steering

Steering Gear Ball Joint 12mm .

Steering Gear Ball Joint 12mm of #:Steering - Steering

Steering Gear Ball Joint 14mm .

Steering Gear Ball Joint 14mm of #:Steering - Steering

Hexagon Nut M12 .

Hexagon Nut M12 of #:Steering - Steering

Cotter Pin 230 .

Cotter Pin 230 of #:Steering - Steering

Hexagon Flange Bolt & Spring Washer & Plain Washer M1035 .

Hexagon Flange Bolt & Spring Washer & Plain Washer M1035 of #:Steering - Steering

Washer 10325 .

Washer 10325 of #:Steering - Steering

Spring Washer ?10 .

Spring Washer Φ10 of #:Steering - Steering

Spring Washer 8 .

Spring Washer 8 of #:Steering - Steering

Plain Washer 8 .

Plain washer 8 of #:Steering - Steering

Insulation Spacer For Horn 2 .

Insulation Spacer For Horn 2 of #:Steering - Steering

Adapter Sleeve, Steering Wheel .

Adapter Sleeve, Steering Wheel of #:Steering - Steering

Connection Strap For Horn .

Connection Strap For Horn of #:Steering - Steering

Horn Spring .

Horn Spring of #:Steering - Steering

Cross Recessed Plate Head Screw M48 .

Cross Recessed Plate Head Screw M48 of #:Steering - Steering

Hexagon Flange Lock Nut M12125 .

Hexagon Flange Lock Nut M12125 of #:Steering - Steering

Circlip D0=17 .

Circlip D0=17 of #:Steering - Steering

Elastic Hoop H .

Elastic Hoop H of #:Steering - Steering

Clamp .

Clamp of #:Steering - Steering

Rubber Boot I .

Rubber Boot I of #:Steering - Steering

Hexagon Nut M14125 .

Hexagon Nut M14125 of #:Steering - Steering

Ball Joint Assy .

Ball Joint Assy of #:Steering - Steering
