Manitou

ID # 17962809

Manitou MSI 25 3B - FT4

Call for Price
Overview

The MSI 25 is a versatile masted forklift truck, unique amongst its kind. It is designed specifically for the timber, paper and recycling sectors and can even find uses within the logistics sector. The hydrostatic transmission combined with the powerful engine and two driven, large-diameter wheels all ensure precise, smooth operation.The MSI 25 comes equipped with a steering axle with an integrated cylinder for a sharper turning radius, allowing for more efficient manoeuvring, to answer the ages old question of how to improve work site productivity on a daily basis. With the large number of attachments available this versatile machine becomes even more so, capable of handling loading, unloading and storing onger loads. Standard maximum capacity is 2.5 tonnes, and can be equipped with masts to reach up to 7 m in lift height.

Specifications
Model
MSI 25 3B - FT4
Category Name
Equipment
Year
2021
Sale Type
New
Manufacturer
Manitou
Wheelbase
180 mm
Rated Speed
2700 rpm
Power Source
Diesel
Max. Capacity
2500 kg
Operator Type
Seated
Overall Width
1323 mm
Overall Length
4045 mm
Service Weight
4070 kg
Turning Radius
2545 mm
Engine Brand / Model
Kubota / V2403 CR TE4
Load Centre Of Gravity
500 mm
Seat Height/stand Height
1025 mm
Engine Power According To ISO 1585
48.60 kW
Fuel Consumption According To VDI Cycle
14.90 l/h
Number Of Cylinders / Capacity Of Cylinders
4 - 2434 cm³
