Model

5HXW030A

5HXY030A

5HXQ030A

Dryer Type

Batch Circulation Mixed Flow

Capacity

(kg)

Rice(560kg/m³）

30000

Corn(690kg/m ³ ）

36000

Wheat(680kg/m³）

35000

Combustion Furnace

Hot Blast Furnace

Oil Burner

Gas Burner

Length*Width*Height(mm)

5843×4467×12681

Ignition Method

Automatic   or manual

Automatic

Automatic

Fuel

Rice Husks, Coconut Husks, Coal,  Wood  Leftovers, Corn Cob

Light Diesel Fuel

Natural Gas

Fuel Consumption

Biomass Fuel

≤230kg/h

25-70L/h

23-94Nm³/h

Coal

≤150kg/h

Supporting Power Supply

3boxes, 380V, 50HZ

Power(kw)

35.8(Excluding Heat Sources)

Weight(kg)

6500

Working   Performance

Feed Time(min)

55-65

Discharge Time(min)

60-70

Drainage Rate(%/h)

0.5-1.2(Rice, Wheat)  1.0-2.0(Corn, Wheat)

Security Settings

Air Pressure Switch,

Hot Air Temperature Detector,

Abnormal Overheating Detector,

Thermal Relay,

Leakage Protection Type Single-phase Circuit Breaker,

Full Volume Detector

Note: The performance and drainage rate listed in the above table are reference values. The actual values will vary due to outside air temperature,  relative humidity, drying type, hot air temperature and moisture content before and after drying.
