Overview
Lovol B504 tractor adopts 12+12 side synchronizer shuttle shift. It is an agricultural model developed for medium and small farms. It is equipped with a high-torque four-cylinder engine, and It is perfectly integrated, more efficient, and more fuel-efficient. Simultaneously, it is equipped with a more robust chassis and synchronizer gearbox, making the operation smoother and bringing more robust durability and reliability. B series compact tractors have the characteristics of high comfort, strong power, efficient work, and responsiveness, bringing you a new experience of high efficiency, multi-function, strong power, and comfortable operation.
Specifications
Model
B504
Category Name
Agriculture
Year
2023
Sale Type
New
Manufacturer
Lovol
ENGINE
Xinchai A498BT
HORSEPOWER(HP)
50
product highlights

1.Adopting Xinchai 498 engine or Doushan D18 engine to meet the Euro Ⅱ, Euro ⅢA, Euro Ⅴ and EPA4 emissions standards, torque reserve coefficient ≥25%, the traction force is up to 13.2 KN. Synchronizer 12F+12R gear, easy to shift; Body appearance upgrade, high handling comfort.

2. Using American Actuant instrument, LOVOL strengthens front axle, good waterproof performance, strengthens chassis and synchronizer gearbox, hydraulic shared-oil lifting, high product reliability; Multiple tire options; Optional intern.

3. 2 groups hydraulic output; Using Category Ⅱ suspension, the most significant lifting force up to  9.1 KN; Optional 6 /8 splines output shaft, optional PTO rotation speed 540/1000, swing traction, can be equipped with a variety of machines and tools to meet the needs of different operations.

4. OECD and EC authentication
product parameters
Item Unit Parameter
Engine
Model / Xinchai A498BT
Horsepower HP 50
Displacement L 3.168
Torque N M ≥180
Transmission
Gearshift / 12+12
Technical route / Synchronizer shift
Speed range km/h 2.37-38.46
PTO speed r/min 540/1000
Hydraulic
Lifting power kN 9.1
Three-point suspension type / Category 1
Hydraulic output flow L/min 32
Number of multi-way valves / 2
Parameter
length*width* height mm 4136×1670×2807
Wheelbase mm 1990
Ground clearance mm 310
Turning radius m 3.8±0.3
Minimum use quality kg 2490
Tire size / 8.3-20/12.4-28
