| Lovol R1804 tractor adopts 16 + 16 synchronizer to shift gears. It is an agricultural model suitable for medium and large farms. R series tractor has the characteristics of comfortable driving, high efficiency, economical and energy-saving, reliable performance, etc. It brings you a new experience of high efficiency, multi-function, lasting power, and comfortable operation. |
|
1. LOVOL TR1804 tractor, designed and manufactured by the European technology team, is a product for dry fields and multi-functional applications. 2. Using the engine satisfies the EuroⅡ emission standards, torque reserve coefficient ≥ 30%, traction force up to 35 KN; Synchronizer 16F+16R gear, easy to shift; Body appearance upgrade, high handling comfort. 3. Using LUK clutch, the United States Actuant instrument, strengthen front axle and chassis; Key parts and components are purchased from all over the world. High product reliability. Various tires are available; optional internal and external air filters; top exhaust; optional cut-off air brake; Adopt rotational molding 50L oil tank. 4. Standard with four groups of hydraulic output,; Using Category Ⅲ suspension(Optional Ⅱ; Double cylinders high-pressure lifter, maximum lifting force up to 45KN; Optional 6 /8 /21 splines switch PTO output spline shaft, PTO rotation speed 540/720/850/1000 optional, swing traction, can be equipped with a variety of agricultural implements, to meet the needs of different operations. 5. OECD authentication ROPS |
| Item | Unit | Parameter |
| Engine | ||
| Model | / | Shangchai 7H |
| Horsepower | HP | 180 |
| Displacement | L | 6.5 |
| Torque | N M | ≥755 |
| Transmission | ||
| Gearshift | / | 16+16 |
| Technical route | / | Synchronizer shift |
| Speed range | km/h | 3.72-33.42 |
| PTO speed | r/min | 540/1000 |
| Hydraulic | ||
| Lifting power | kN | 45 |
| Three-point suspension type | / | Category 3 |
| Hydraulic output flow | L/min | 80 |
| Number of multi-way valves | / | 4 |
| Parameter | ||
| length*width* height | mm | 5300×3400(双胎)×3150 |
| Wheelbase | mm | 2720 |
| Ground clearance | mm | 450 |
| Turning radius | m | 5.3±0.3 |
| Minimum use quality | kg | 7950(Double rear tires) |
| Tire size | / | 16.9-28/20.8-38(Double rear tires) |
