• The open frame design with large clearances guarantees blockage-free operation even in high amounts of organic mass.
• The 620 mm diameter concave discs overlap between rows to ensure that all soil is moved even at shallow working depths.
• Legs are mounted on strong hinges, with overload protection via robust spiral springs, to ensure the discs stay on track even in difficult conditions.
• Each row of the notched discs has height and angle adjustable rebound harrows, controlling the soil flow from the discs and, when working diagonally across the rows, helping to complete a thorough straw distribution.
• In working widths of 4 to 6 metres, the semi-mounted Rubin 9 can be fitted with a light, transport axle, or with a combination axle for use together with the Solitair pneumatic seed drill.

Gigant 10 S/800 Rubin 9 U

• Drawbar eye Ø 58 mm, for connection to a double lashing drawbar (or Ø 48 mm)
• Axle with wheels 550/45-22.5, 1,070 x 550 mm
• Depth control
• Underframe clearance 80 cm
• Two integrated harrows
• Concave discs with overload safety device 620 x 6 mm notched
• Three point linkage hydraulic double acting
• Without roller
• Without lighting equipment
• Without brake system

Gigant 12 S/1000 Rubin 9 U

• Drawbar eye Ø 58 mm, for connection to a double lashing drawbar (or Ø 78 mm)
• Axle with wheels 580/65-22.5, 1,300 x 580 mm
• Depth control
• Underframe clearance 80 cm
• Two integrated harrows
• Concave discs with overload safety device 620 x 6 mm notched
• Three point linkage hydraulic double acting
• Without roller
• Without lighting equipment
• Without brake system

Gigant 12 S/1200 Rubin 9 U

• Drawbar eye Ø 58 mm, for connection to a double lashing drawbar (or Ø 78 mm)
• Axle with wheels 800/40-26.5, 1,340 x 800 mm
• Depth control
• Underframe clearance 80 cm
• Two integrated harrows
• Concave discs with overload safety device 620 x 6 mm notched
• Three point linkage hydraulic double acting
• Without roller
• Without lighting equipment
• Without brake system
