ID # 13240204

Landoll Industrial Tag Model L4024

  • Landoll Industrial Tag Model L4024
  • Landoll Industrial Tag Model L4024
  • Landoll Industrial Tag Model L4024
  • Landoll Industrial Tag Model L4024
  • Landoll Industrial Tag Model L4024
  • Landoll Industrial Tag Model L4024
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Landoll_Trailer_IndustrialTag_4024_WoodFiller_270x160.jpg 40,000 lb. Capacity



The 40,000 lb. capacity L4024 features a loaded deck height of 32" by design of a pierced main beam.  Standard suspension is 45,000 lb. multi-leaf spring, while the brakes are 12.25x7.5 Full Air ABS, 4S2M.  Other standards are a bucket trough, ten combination stake pocket/chain gotchas built into the frame and durable powder coat paint finish.



  Features
  • Conc. Deck Rating: 40,000 Lbs. In 10 ft. area
  • *Capacity: 40,000 lbs.
  • Estimated Base Weight: 8,500 Lbs.
  • Main Frame: I-Beam
  • Crossmembers: 4" Jr. I-Beams on 12" Centers, 80,000# PSI
  • Side Rail: 9" Deep Formed Steel Side Rails
  • Jacks: 12,000 Lb. Quick Lift Parking Jacks
  • Tires: 215/75Rx17.5 LRH Goodyear
  • Wheels: Hub Pilot/Steel Outboard Brake Drums
  • Axles: 2 - 25,000 Lbs. Dual Tire, Oil Seal Hubs
  • Suspension: Multi-Leaf Springs 45,000 Lb. Capacity
  • Brakes: 12.25x7.5 Full Air AB, 4S2M
  • Hitch: Heavy Duty Pintle Eye Hitch Adjustable 20" to 30" Safety Chains - Eyelet 15,000# Vertical; 60,000# Total Capacity
  • Headboard: 6" Headboard
  • Decking: 2" Nominal Fir
  • Loaded Deck Height: 32 Inches
  • Width: 102" Wide
  • Length: 24' Deck (19' Flat Deck + 5' Beavertail)
  • Beavertail: 5' Self Cleaning Beavertail
  • Ramps: 5' Self Cleaning Adjustable Spring-Assisted Flip-over Ramps
  • Lights: Sealed Beam System with Sealed Wiring Harness D.O.T. Approved
  • Tie Downs: 10 Double Key Hole Chain Locks-Gotchas/Stake Pockets
  • Finish: High-Quality Powder Paint
  • Color: Yellow, Black, White
  • Decals: Hi-Visibility Reflective Package



   Technical Specifications:



MODEL
CAPACITY
BASE WEIGHT
  DECK AXLES
TIRES & PLY RATING
L4024
20 Ton
8,500 lbs.
 24' 2 (8) 215/75Rx17.5 LRH



Specifications
Model
Industrial Tag Model L4024
Category Name
Trailers - Highway/Semi
Year
2014
Sale Type
New
Manufacturer
Landoll
