ID # 13240199

Landoll Industrial Tag Model L2424

  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
  • Landoll Industrial Tag Model L2424
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Landoll_Trailer_IndustrialTag_2424_Xmembers_270x160.jpg 24,000 lb. Capacity



The L2424 is a 2 axle 24,000 lb. capacity tag trailer designed to haul a variety of construction equipment.  The trailer is constructed with 4" Jr. I-Beams 80,000 PSI material for the crossmembers and 8" formed side rails.  Standard features include ten combination stake pocket/chain gotchas, bucket trough and powder coat paint finish.



  Features
  • Conc. Deck Rating: 20,000 Lbs. In 10 Ft. area
  • *Capacity: 24,000 lbs.
  • Estimated Base Weight: 6,000 Lbs.
  • Main Frame: I-Beam
  • Crossmembers: 4" Jr. I-Beams on 16"Centers 80,000# PSI
  • Side Rail: 8" Deep Formed Steel Side Rails
  • Jack: 12,000 Lb. Quick Lift Parking Jack
  • Tires: 235/80R 16 LRE
  • Wheels: Dual Disc Wheels - 8 Hole
  • Axles: 2-12,000 Lbs. Axles with Oil Seal Hubs
  • Suspension: Spring Suspension (3" wide)
  • Brakes: 12-1/4"x 5" Electric Brakes
  • Hitch: Heavy Duty Pintle Eye Hitch Adjustable 20" to 30" with Safety Chains
  • Headboard: 6" Headboard
  • Decking: 2" Nominal Fir
  • Loaded Deck Height: 35 Inches
  • Width: 102" Wide
  • Length: 24' Deck (19' Flat Deck + 5' Beavertail)
  • Beavertail: 5' Self Cleaning Beavertail
  • Ramps: 5' Self Cleaning Adjustable Spring Assisted Flip-over Ramps
  • Lights: Sealed Beam System with Sealed Wiring Harness D.O.T. Approved
  • Tie Downs: 10 Double Key Hole Chain Locks-Gotchas/Stake Pockets
  • Finish: High Quality Powder Paint
  • Color: Yellow
  • Decals: Hi-Visibility Reflective Package



   Technical Specifications:



MODEL
CAPACITY
BASE WEIGHT
  DECK AXLES
TIRES & PLY RATING
L2424
24,000 lbs.
6,000 lbs.
 24' 2 (8) 235 80R 16 LRE



Specifications
Model
Industrial Tag Model L2424
Category Name
Trailers - Highway/Semi
Year
2014
Sale Type
New
Manufacturer
Landoll
