Lounge cab: your new office in first class

The Lounge Cab is a new-concept four-post design with rear hinged doors that provides unobstructed visibility in all directions, giving the driver full view of blind spots without the need to change position. The cab is pressurized to keep a clean, dust-free environment and a highly-efficient sound insulation system maintains an in-cab noise level of only 70 dB for maximum comfort of operation. The optional electrohydraulic cab suspension system further enhances the operator comfort. Wide, well-spaced access steps allow the operator to easily get in and out of the cab, while the buddy seat neatly folds away making for easier and safer access. The cab interior features an automotive-style fit and finish with easy-clean soft-touch materials. The instrument panel tilts with the steering wheel to suit the driver’s need. The alcantara swivel seat with dynamic air suspension system and fully automatic height adjustment features backrest heating and ventilation for ultimate driving comfort.



  Ftp nef engines: efficiency that improves your productivity

 Eight models in the range are all powered by the new FPT NEF turbo engines with four valves per cylinder and common rail injection system. The 7-145, 7-165 and 7-175 models feature self-supporting 4.5L, four-cylinder engines with power ratings of 141, 155 and 166 hp. The 7-165, 7-180, 7-200, 7-220 and 7-230 models are equipped with 6.7L, six-cylinder engines located within a rugged chassis which helps reduce noise and vibration levels within the cab. The six-cylinder models deliver power outputs of 151, 165, 180, 190 and 205 hp. These new engines meet the Stage4/Tier4 Final emissions regulations using a selective catalytic reduction system (SCR) combined with a diesel oxidation catalyst (DOC). The new FPT NEF powering the 7 Series is an advanced engine designed to offer farmers simplicity and functionality without compromising on performance, reliability and durability.

Robo-six transmission: high efficiency and smooth driving



High performance, fuel efficiency, smooth driving and safety are the strong points of the Robo-Six transmission. The key features of this transmission include five speed ranges, a six-speed on-the-go powershift, a robotized range shifting and an electrohydraulic steering-column power shuttle. The Robo-Six transmission offers 30 forward and 15 reverse speeds. In addition, a creep speed option provides 54 speeds forward and 27 in reverse. The 7 Series features the Eco Forty mode that provides a top speed of 40 km/h at reduced engine rpm. Where legally permitted, a top speed of 50 km/h can be reached with the Eco Fifty mode. In addition, the Robo-Six transmission is equipped with an oil cut-off function which manages the braking system more efficiently, thus ensuring better performance on the road and improved fuel economy.

  Hydraulic system tailored to your specific needs

Designed to provide high-flow capability, the hydraulic system of 7 Series features high-quality components and provides unmatched configuration flexibility to meet the farmers’ specific requirements. The hydraulic system is a closed-centre circuit with variable-displacement pump. This means that the pump always delivers exactly the quantity of oil that the system requires, thereby eliminating unnecessary power waste. The system supplies up to 123 l/min to the hitch and remote valves, allowing for simultaneous operation of all hydraulic functions. For the Dynamic Robo-Six versions a high-flow pump with a total flow of 160 l/min is available as an option. The Active Robo-Six models come standard with an open-centre hydraulic system providing a total flow of 88 l/min. A closed-centre system with a total flow of 123 l/min can be supplied as an option.
