Versatile transmission to suit every need

The REX4 tractors feature as standard a Speed Four modular transmission with four synchronized gears and three ranges that provide 12 forward and12 reverse speeds. Transmission options include a Power Four module (Hi-Lo splitter) providing 32 forward and 32 reverse speeds, a T-Tronic three-stage powershift (high-medium-low) giving a total of 48 forward and 16 reverse speeds, and a creeper that provides speeds as low as 300 m/h at maximum engine rpm.

Innovative hydraulic system for maximum flexibility

The REX4 comes with a variety of hydraulic options and configurations to offer farmers tailored solutions for their applications. The hydraulic system of the REX4 range comes standard with a double pump that supplies 50 l/min to the rear hitch and remotes and 28 l/min to the steering system. Optionally, it can be equipped with a triple pump that provides a flow rate of 44+41+28 l/m to operate, respectively, the rear hitch and remotes, the front remotes and the steering system. The tractor can be equipped with up to seven remote valves, four at the rear and three at the front. Available options include three electrohydraulic front remotes, a flow selector to control multiple outlets with a single control and a flow divider to regulate the flow rate to the remotes. The F and V models can be equipped with rear hydraulic stabilizers which control opening and closing of the lower links via two simple push-buttons. This function can be useful when attaching implements or when hitch adjustment during inter-row operation is required.

DIMENSIONS AND WEIGHTS
