Landini

ID # 13217683

3640 / 3640H

Call for Price
Overview
    With four horsepower sizes offered in a rugged open station platform, Landini has your compact tractor needs covered.  With a variety of transmission options including an available hydrostatic transmission and mid-PTO these compacts make easy work of your day-to-day chores.  Standard features including wet-disc brakes, conveniently positioned levers, and an ergonomic platform make everyday work a pleasure. Ideally suited for the small farmer, landscaper or estate owner these compacts will tackle the toughest tasks without difficulty.



Specifications
Model
3640 / 3640H
Category Name
Tractors
Year
2014
Sale Type
New
Manufacturer
Landini
Gross Horsepower
38
Rated Speed(rpm)
2700
No Of Cylinders
4
Fuel Tank (gal)
32 (8.5)
Transmission
AVAILABLE IN SHUTTLE SHIFT OR TWO PEDAL HYRDROSTATIC TRANSMISSION
Displacement Cu In (l)
107 (1.8)
Air Cleaner
Dry Dual Element
Cold Starting Aid
Glow Plug
Cooling System
Water- cooled
Alternator
12V-50A
Hydraulic Flow To Remotes
HIGH PERFORMANCE HYDRAULICS
Remote Valves
2
Steering Type
Hydrostatic
Ground Clearance
13 (33)
Weight Lb (Kg)
2711 (1230)
Type
Vertical, Indirect
Bore Stroke In(mm)
3.07/3.09 (78/78.5)
Length (cm)
118 (299)
Height (cm)
91 (231)
Width (cm)
58 (147)
Wheel Base In (cm)
65 (166)
Turning Radius W Brake In (cm)
101 (256)
Lift Capacity @ Ball End Lb (kg)
2620 (1182)
Main Pump Lmin (gal Min)
30.8 (8.1)
Steering Pump L Min (galmin
13.6 (3.6)
Turning Radius Wo Brake In (cm)
114 (290)
Basic Transmission (opt)
12x12 / HST+3 rng h
Creeper
opt N/A
Forward Speed Range (kph)
1.08~ 28.7 / 0~ 24.37h
Reverse Speed Range (kph)
1.17~ 28.7 / 0~ 17.8h
Main Gear Shift Type
Synchro
Range Gear Shift Type
Gear Sliding
Rear Differential Lock
Mechanical
Brake Type
wet, multi disc/ 4740 / 4740H
