ID # 38425691

LS Tractor MT473PS Utility Tractors

  • LS Tractor MT473PS Utility Tractors
  • LS Tractor MT473PS Utility Tractors
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
  • MT4 redesigned with new LS Family Look. New hood design allows for improved engine performance and serviceability
  • LED Lamps for all models provide better illumination for more efficient work in darker operating conditions
  • Larger tire size options which provide better grip and traction with lower ground pressure.
  • 15% more space in new cab design than previous model allows for more comfort and convenience in the same footprint. Additionally, the redesigned cab offer improved access to key components for easier diagnosis and routine maintenance
  • Improved high back for seat with wider and improved cushion for greater operator comfort
  • Enhanced lift height (up to 132.9” in max height mode) and capacity (3,487 lb in max power mode) for front loader (LL5001) with standard self leveling bucket
  • Standard 2 sets of remote valves. Adds functionality and improves ease of use by allowing attachment of hydraulically controlled implements without the high, additional costs like others in its class to add the remotes as options.
  • Extendable lower links. Category 2 with hitch lift capacity of 4,079 lbs. allows easier attachment of a wide variety of implements.
  • Standard 3rd function button on joystick
Specifications
Model
MT473PS Utility Tractors
Category Name
Tractors
Year
2025
Sale Type
New
Manufacturer
LS Tractor
Total Weight Without Ballast (lbs.)
5,423
engine
Type
Vertical Water-Cooled 4 Cycle Diesel Engine
PTO HP
62.9
Model (Tier 4 )
L4C25-T
Engine HP (Gross)
73
Rated Speed (RPM)
2,500
Displacement (cu In.)
152.85
Fuel Tank Capacity (gal)
24.3
drive train
Brakes
Wet, Multi-disc
No. Of Speeds
F16 X R16
Transmission Type
Electro Power Shuttle
Steering Hydrostatic Power
Steering
pto
Type
Independent
Rear, Rpm
540, 540E (Standard)
hydraulic system
Remote Valves
2 Pairs (Front), 2 pairs (Rear)
Control System
Position/Draft
Total Flow (gpm)
21.1
Steering Pump (gpm)
6.6
Category, 3 Pt Hitch
CAT II
Implement Pump (gpm)
14.5
Hitch Lift Capacity, Lbs (Hitch End)
3,483 (@ 24˝ from the Hitch end)
dimension
Wheelbase (in.)
83.1
Height To Top (in.)
113.9
Overall Width With Tires (in.)
72.6
Overall Length (Frame To Link, In.)
135
tire size
Ag Front / Rear
9.5 – 24 / 16.9 – 28
IND Front / Rear
10.5/80×18 10PR / 19.5Lx24 8PR
R14 Front / Rear
320-85R20 119D / 420/75R34 142D
Large Ag Front / Rear
11.2-24 / 16.9-30
options

Standard

Remote Valve – 2 Pairs
Loader Valve – 2 Pairs
Engine Kill Switch
Seat With Suspension & Armrest
Telescopic Lower Link
External Lift Control Lever
Drawbar
Linked Pedal
RH Step
Tool Box

Options

Tail Pipe ROPS Vertical Kit
DIA Rear Ballast Kit
Step Sub RH DIA Kit
Air Ride Seat Cab DIA Kit
Seat Assy-Fab-Ls Gray-Trg850
Cab Room Mirror Cab DIA Kit
Gear Range TRG285
3rd Function Cab Kit
3rd Function ROPS Kit
External Position Lever
Drawbar Kit General
Drawbar Kit Clevis
Remote Control Valve Spring 2S Kit
Remote Control Valve Spring 3S Kit
Remote Control Valve Detent 2S Kit
Remote Control Valve Detent 3S Kit
literature
Name Link
LS Model Comparison Download
