LS Tractor MT225E Compact Tractors

  • LS Tractor MT225E Compact Tractors
  • LS Tractor MT225E Compact Tractors
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
  • 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
  • Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
  • Standard 12×12 Synchro Shuttle – Change gears without having to stop. 12 forward / 12 reverse gear transmission provides more operating speeds than others in its class for superior control, precision and safe operations for virtually any application.
  • Side Mounted Main Gear Lever – Maximizes space and makes getting on and off tractor easier than straddle type like other brands.
  • Standard Hydrostatic Gear Lever – Makes turning easier, improves control and reduces fatigue.
  • Standard Foldable ROPS – Allows Storage in low clearance buildings or sheds.
  • Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
  • 3-Point Hitch – Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
  • Ergonomically Designed 3-Point Hitch Controls – Easily accessible for maximum comfort and convenience with hydraulic position control.
  • Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
  • Large Fuel Tank – Provides long operation times between fill ups.
  • Standard Rubber Mat – Reduces noise, vibration and prevents slipping.
  • Flat Platform And Rubber Mat – Roomy, spacious and comfortable.
  • Mitsubishi Tier 4 Engine – Fuel efficient engine delivers reliable performance. Rubber engine mounts reduce operator platform vibration. Standard preheat starting aid improves cold weather starting.
  • Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
  • Modern Ergonomic Design – This compact is ergonomically designed.
  • Deluxe Adjustable Seat With Seat Belt – Keeps you in a comfortable and safe position for maximum control.
Specifications
Model
MT225E Compact Tractors
Category Name
Tractors
Year
2025
Sale Type
New
Manufacturer
LS Tractor
Total Weight Without Ballast (lbs.)
2,434
engine
Type
3 Cylinder, liquid-cooled, Diesel, NA, IDI
PTO HP
19.2
Model (Tier 4 )
Mitsubishi S3L2
Alternator (V-A)
12V – 50 Amps
Engine HP (Gross)
24.6
Rated Speed (RPM)
2,500
Displacement (cu In.)
80.4
Fuel Tank Capacity (gal)
7.4
drive train
Brakes
Wet, Multi-disc
Steering
Hydrostatic Power Steering
No. Of Speeds
F12 x R12
Transmission Type
Synchro shuttle
pto
Type
Independent
Rear, Rpm
540 (Standard)
hydraulic system
Remote Valves
Option
Control System
Position
Total Flow (gpm)
12.5
Steering Pump (gpm)
4.6
Category, 3 Pt Hitch
CAT I
Implement Pump (gpm)
7.9
Hitch Lift Capacity, Lbs (Hitch End)
1,808
dimension
Wheelbase (in.)
66
Height To Top (in.)
88
Overall Length (Frame To Link, In.)
118
tire size
Ag Front / Rear
7 – 14 / 11.2 – 24
IND Front / Rear
25 x 8.5 – 14 / 43 x 16 – 20
Turf Front / Rear
25 x 8.5 – 14 / 41 x 14 – 20
options
Remote Valve- 1 pair (2 outlets) or 2 pair (4 outlets)
Detent Kit
Work Light
Horn
Front Weight – 44 lbs. x 4
literature
Name Link
LS Model Comparison Download
