LS Tractor MT232H Compact Tractors

  • LS Tractor MT232H Compact Tractors
  • LS Tractor MT232H Compact Tractors
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
  • Redesigned air conditioning and roof configuration, providing additional head space and increased forward visibility
  • Much improved seat comfortability
  • Cruise control & linked pedal functionalities (Engine RPM matches user input demand on F/R HST pedals)
  • New hood design (LS Family look), Grill open space plus 20%
  • LED head Lamp
  • 1 Inch large tire size and four different tire options
  • Larger lifting capacity, loader lifting capacity of New MT226E (LL3301/2) 1,965 lbs. New MT2E & MT2 (LL3303) 2,506lbs.
  • Workability, 4-point mount structure as well as digging depth of 97.2” and bucket digging force of 3,663lbs.
  • TF-LCD instrument panel providing various information like, regen time, oil change interval, etc.
  • E/G RPM interlocking switch (STD). When working at low RPM, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/lift.
Specifications
Model
MT232H Compact Tractors
Category Name
Tractors
Year
2025
Sale Type
New
Manufacturer
LS Tractor
Total Weight Without Ballast (lbs.)
3,254
engine
Type
3 Cylinder Liquid-cooled Diesel, NA, CRDII
PTO HP
26.2
Model (Tier 4 )
YANMAR
Alternator (V-A)
12V – 50 Amps
Engine HP (Gross)
31.7
Rated Speed (RPM)
2,600
Displacement (cu In.)
100.2
Fuel Tank Capacity (gal)
10.6
drive train
Brakes
Wet, Multi-disc
Steering
Hydrostatic Power Steering
No. Of Speeds
3 Ranges
Transmission Type
HST
pto
Type
Independent
Rear, Rpm
540 (Standard)
hydraulic system
Remote Valves
1 Pair
Control System
Position
Total Flow (gpm)
11.7
Steering Pump (gpm)
5
Category, 3 Pt Hitch
CAT I
Implement Pump (gpm)
6.7
Hitch Lift Capacity, Lbs (Hitch End)
1,808
dimension
Wheelbase (in.)
69
Height To Top (in.)
95
Overall Width With Tires (in.)
66
Overall Length (Frame To Link, In.)
125
tire size
Ag Front / Rear
7 – 14 / 11.2 – 24
VT Front / Rear
27X8.50-15 / 43X16.00-20
IND Front / Rear
27X8.50-15 / 43X16.00-20
Turf Front / Rear
25X8.50-14 / 41X14.00-20
options

Standard

Remote valve 1st
Loader valve 3pair
E/G RPM Interlocking Switch(Joystick)
Cruise Control & Linked Pedal
Lowerlink – Telescopic
Stabilizer – Check Link
External Lift Control Lever
Drawbar
Head Lamp(LED)
TF LCD Instrument Panel
12V Outlet
Engine Kill Switch(Rear Fender)
Rubber Mat
Seat with Suspension & Armrest
LH/RH Side Step
Tool Box

Options

3rd Function Extension Pipe
Remote valve 2nd
Mid PTO
Clevis Drawbar
Rear Work Lamp
7-pole
Horn
Fuel Cap(Locking Type)
Block Heater
literature
Name Link
LS Model Comparison Download
