LS Tractor MT122 Sub-Compact Tractor

  • LS Tractor MT122 Sub Compact Tractor
  • LS Tractor MT122 Sub Compact Tractor
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
  • 4WD (Front Wheel Mechanical Assist) – The MT125-24.7HP Sub-Compact Tractor features 4WD so you can get all your heavy duty pulling with no scuff. Go from 2WD to a 4WD with a simple move of a lever.
  • Dual Pedal, 2 Range HST – Our MT125 model features the highly preferred dual pedal. Easier and more comfortable than rocker pedals and smoother switch.
  • Independent PT – Easiest PTO to operate that can be turned on or off with a switch.
  • PTO Selector Switch – Allows you to select the rear-PTO, mid-PTO or both.
  • Standard Mid PTO – 2000 RPM Mid PTO for optional 60” mid-mount mower or 50” front mount snow blower.
  • Standard Hydrostatic Power Steering – Ditch the mechanical link—introducing hydrostatic power steering for ultimate flexibility, parts costs, and assemble-ability. This feature makes turning easier, improves control and reduces fatigue.
  • Standard Foldable Props – Introducing foldable ROPS for storage allowance in low clearance buildings or sheds.
  • 3-Point Hitch – Category 1 with a hitch lift capacity of 966 lbs. is smooth and responsive.
  • Ergonomically Designed 3-Point Hitch – Category 1 with a hitch lift capacity of 966 lbs. is smooth and responsive.
  • Ergonomically Designed 3-Point Hitch Controls – Easily accessible for maximum comfort and convenience with hydraulic position control.
  • Easily Adjust Mowing Height – Adjusting the cutting height for the available 60″ mid-mount mower is as easy as turning a dial.
  • Toolbox – Convenient storage keeps tools handy.
  • Yanmar Tier 4 Engine and Easy Open Hood – Tier 4 engine that provides reliable power and performance. Includes an Easy Open Hood for quick accessibility for easy maintenance.
  • Modern Ergonomic Design – This small chassis compact is ergonomically designed and stylish.
  • Comfortable High-Back Seat – Supportive and comfortable seat reduces fatigue and reverses position for backhoe use.
Specifications
Model
MT122 Sub-Compact Tractor
Category Name
Tractors
Year
2025
Sale Type
New
Manufacturer
LS Tractor
Total Weight Without Ballast (lbs.)
1,433
engine
Type
3-cylinder, Indirect-injection, Water-cooled
PTO HP
15
Model (Tier 4 )
Yanmar 3TNV76F
Alternator (V-A)
12V – 40
Engine HP (Gross)
21.5
Rated Speed (RPM)
3,000
Displacement (cu In.)
68
Fuel Tank Capacity (gal)
6.6
drive train
Brakes
Wet, Multi-Disc
Steering
Hydrostatic Power Steering
Transmission
Hydrostatic Drive
No. Of Speeds
2 Ranges
pto
Type
Independent
Mid PTO
Standard (2500 rpm)
Rear PTO
Standard (540 rpm)
hydraulic system
Control System
Position
Total Flow (gpm)
6.7
Steering Pump (gpm)
2.1
Category, 3 Pt Hitch
CAT 1
Implement Pump (gpm)
4.6
Hitch Lift Capacity (lb.)
970 (728 @ 24”)
dimension
Wheelbase (in.)
56
Height To Top Of ROPS (in.)
87
TIRE SIZE Industrial Front/Rear
18×18.5 – 10/26 x 12.0 – 12
Overall Length (Bumper To Link, In.)
97
Min. Overall Width With IND Tires (in.)
47
tire size
Ag Front / Rear
7 – 14 / 11.2 – 24
VT Front / Rear
27X8.50-15 / 43X16.00-20
IND Front / Rear
27X8.50-15 / 43X16.00-20
Turf Front / Rear
25X8.50-14 / 41X14.00-20
options
Draw Bar
Rear Remote Valve – 1 Set
Work Light
Detent
Cab
literature
Name Link
LS Model Comparison Download
Competitive Comparison Download
