ID # 13247402

Kuhn Knight ProSpread Apron Box Spreaders

  • Kuhn Knight ProSpread Apron Box Spreaders
  • Kuhn Knight ProSpread Apron Box Spreaders
  • Kuhn Knight ProSpread Apron Box Spreaders
  • Kuhn Knight ProSpread Apron Box Spreaders
  • Kuhn Knight ProSpread Apron Box Spreaders
  • Kuhn Knight ProSpread Apron Box Spreaders
  • Kuhn Knight ProSpread Apron Box Spreaders
  • Video Button Hqdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Kuhn Knight is the leader in innovative box spreaders, with over 60 years of experience. Apron and push-type box spreaders are available to spread all types of solid materials. The ProPush and Commercial ProSpread models are available in several beater options for consistent spreading to maximize nutrient value.
  Features


  Specifications 1130 1140 PS 150 PS 160 PSC 161 PSC 171 PSC 181
  Capacity - no extensions (m3) 9 10.5 14 17 17 20 23
  Capacity - no extensions (cu.ft) 320 380 500 600 610 710 810
  PTO speed (rpm) 540/1000 540/1000 540/1000 1000 1000 1000 1000
  Overall tread width (cm) 259 259 330 330 270 270 270
  Overall tread width (in) 102 102 130 130 108 108 108
  Overall height - w/horizontal beaters (m) 1.9 2 2.1 2.1 2.8 3 3
  Overall height - w/horizontal beaters (in) 74 78 81 83 110 117 117
  Overall height - w/vertical beaters (m) - - 2.8 2.8 3.5 3.7 3.7
  Overall height - w/vertical beaters (in) - - 111 112 139 144 144
  Spinner beater diameter (in) - - - - 41 41 41
  Spinner beater diameter (m) - - - - 104 104 104
  Overall length – w/ spinner beaters (m) - - - 8.7 8.2 9.1 10
  Overall length – w/ spinner beaters (in) - - - 343 321 358 394
  Overall height – w/ spinner beaters (in) - - - - 133 138 138
  Overall height – w/ spinner beaters (m) - - - - 3.4 3.5 3.5
  Overall length - w/vertical beaters (m) - - 7.9 8.8 8.3 9.2 10
  Overall length - w/vertical beaters (in) - - 310 347 325 362 398
  Overall length - w/horizontal beaters (m) 6.3 6.9 7.3 8.3 7.8 8.7 9.7
  Overall length - w/horizontal beaters (in) 248 272 289 326 307 344 380
  Maximum load (kg) 9525 11340 14969 17237 17917 20865 23814
  Maximum load (lb) 21000 25000 33000 38000 39500 46000 52500
  Minimum power requirement for PTO (kW) 56 67 - - 119 142 164
  Minimum power requirement for PTO (hp) 75 90 - - 160 190 220
  Minimum power requirement for PTO - w/ vertical beaters (kW) - - 104 119 - - -
  Minimum power requirement for PTO - w/ vertical beaters (hp) - - 140 160 - - -
  Minimum power requirement for PTO - w/ horizontal beaters (kW) - - 89 104 - - -
  Minimum power requirement for PTO - w/ horizontal beaters (hp) - - 120 140 - - -
  Minimum Power requirement for PTO w/ spinner beaters (hp) - - - 160 - - -
  Minimum Power requirement for PTO w/ spinner beaters (kW) - - - 119 - - -
  Spinner beater diameter (in) - - - 41 - - -
  Spinner beater diameter (cm) - - - 104 - - -
  Beaters - number standard 1 1 2 2 2 2 2
  Beater diameter - lower (cm) 66 66 - - - - -
  Beater diameter - lower (in) 26 26 - - - - -
  Horizontal beater diameter (cm) - - 51 51 51 51 51
  Horizontal beater diameter (in) - - 20 20 20 20 20
  Vertical beater diameter (cm) - - 96 96 103 103 103
  Vertical beater diameter (in) - - 38 38 40.5 40.5 40.5
  Removeable beater assembly No No Yes Yes Yes Yes Yes
  Loading height (cm) 145 165 183 203 264 284 284
  Loading height (in) 57 65 72 80 104 112 112



Specifications
Model
ProSpread Apron Box Spreaders
Category Name
Agriculture
Year
2015
Sale Type
New
Manufacturer
Kuhn Knight
