Kuhn Knight EasySpread Apron Box Spreaders

  • Kuhn Knight EasySpread Apron Box Spreaders
  • Kuhn Knight EasySpread Apron Box Spreaders
  • Kuhn Knight EasySpread Apron Box Spreaders
  • Kuhn Knight EasySpread Apron Box Spreaders
  • Kuhn Knight EasySpread Apron Box Spreaders
  • Video Button Hqdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Kuhn Knight is the leader in innovative box spreaders, with over 60 years of experience. Apron and push-type box spreaders are available to spread all types of solid materials. The ProPush and Commercial ProSpread models are available in several beater options for consistent spreading to maximize nutrient value.
  Features


  Specifications 1212 1215 1219 1224 1230
  Capacity - no extensions (m3) 3.3 4.1 5.4 6.8 8.4
  Capacity - no extensions (cu.ft) 117 146 189 240 295
  PTO speed (rpm) 540 540 540 540 540
  PTO protection Yes Yes Yes Yes belt slip Yes belt slip
  Tread width (cm) 183 198 206 254 254
  Weight (kg) 726 816 1111 1247 1497
  Weight (lb) 1600 1800 2450 2750 3300
  Maximum load (kg) 2386 2980 3858 4899 6021
  Maximum load (lb) 5260 6570 8505 10800 13275
  Minimum power requirement for PTO (kW) 22 26 34 48 56
  Minimum power requirement for PTO (hp) 30 35 45 65 75
  Beaters - number standard 1 1 1 1 1
  Beater diameter - lower (cm) 66 66 66 66 66
  Beater diameter - lower (in) 26 26 26 26 26
  Box type Apron Apron Apron Apron Apron
  Removeable beater assembly No No No No No
  Loading height (cm) 113 117 122 119 119
  Loading height (in) 45 46 48 47 47
  Box width - inside (cm) 122 122 122 152 152
  Box width - inside (in) 48 48 48 60 60



Specifications
Model
EasySpread Apron Box Spreaders
Category Name
Agriculture
Year
2015
Sale Type
New
Manufacturer
Kuhn Knight
