With the most complete TMR mixer line on the market today, Kuhn North America has the right mixer to meet your needs, whether you are mixing 100% hay or 100% grain or any ration in between. The Reel Auggie and Commercial Reel Mixers provide superior mix quality. Vertical Maxx Mixers mix the widest variety of feedstuffs, including round bales. The 4-Auger machines allow incorporation of up to 50% alfalfa hay and require less horsepower than other types of mixers.

Features

Specifications 3115 3120 3125 3130 3136 3142 RA 136 RA 142 RC 250 RC 260 RC 270 RC 295   Capacity - no extensions (m3) 4.2 6.1 7.1 8.5 10.2 11.9 10.2 11.9 14.2 17 19.8 27   Capacity - no extensions (cu.ft) 147 216 250 300 360 420 360 420 500 600 700 950   Number of augers 2 2 2 2 2 2 2 2 2 2 2 2   Overall height - no extensions (cm) 196 213 224 224 259 259 262 262 272 272 272 320   Overall height - no extensions (in) 77 84 88 88 102 102 103 103 107 107 107 126   Overall width - without options (cm) 224 224 239 239 258 258 251 251 259 259 259 305   Overall width - without options (in) 88 88 94 94 101.5 101.5 99 99 102 102 102 120   Tread width (cm) 208 208 213 213 239 239 239 239 257 257 257 279   Tread width (in) 82 82 84 84 94 94 94 94 101 101 101 110   Weight (kg) 1687 2800 3523 3884 4623 4968 4713 5103 6713 7257 8981 11090   Weight (lb) 3720 6173 7771 8562 10192 10953 10390 11.250 14800 16000 19800 24450   Minimum power requirement for PTO (kW) 34 37 41 45 56 67 56 67 75 82 89 127   Minimum power requirement for PTO (hp) 45 50 55 60 75 90 75 90 100 110 120 170   Maximum load (kg) 2000 2939 3402 4082 4899 5715 4899 5715 6803 8165 9525 12927   Maximum load (lb) 4410 6480 7500 9000 10800 12600 10800 12600 15000 18000 21000 28500   Door opening (h x w, cm) 51 x 41 91 x 51 91 x 51 91 x 51 91 x 51 91 x 51 91 x 51 91 x 51 107 x 56 107 x 56 107 x 56 122 x 66   Door opening (h x w, in) 20 x 16 36 x 20 36 x 20 36 x 20 36 x 20 36 x 20 36 x 20 36 x 20 42 x 22 42 x 22 42 x 22 48 x 26   Reel arms 4 4 4 4 4 4/5 5 5 5 5 5 5   Reel diameter (cm) 132 132 152 152 173 173 173 173 178 178 178 213   Reel diameter (in) 52 52 60 60 68 68 68 68 70 70 70 84   Reel speed (rpm) 5.1 7.13 7.26 7.26 6.5 6.5 6.25 6.25 5.8-6.4 5.8-6.4 5.6-6.8 4.6-5.2   Auger diameter - lower (cm) 41 41 46 46 51 51 51 51 61 61 61 71   Auger diameter - lower (in) 16 16 18 18 20 20 20 20 24 24 24 28   Auger diameter - upper (cm) 36 36 46 46 51 51 51 51 56 56 56 71   Auger diameter - upper (in) 14 14 18 18 20 20 20 20 22 22 24 28
