With the most complete TMR mixer line on the market today, Kuhn North America has the right mixer to meet your needs, whether you are mixing 100% hay or 100% grain or any ration in between. The Reel Auggie and Commercial Reel Mixers provide superior mix quality. Vertical Maxx Mixers mix the widest variety of feedstuffs, including round bales. The 4-Auger machines allow incorporation of up to 50% alfalfa hay and require less horsepower than other types of mixers.

Features

Specifications 5127 5135 5143 VSL 142 VSL 150   Capacity - no extensions (m3) 7.6 9.9 12 12 14   Capacity - no extensions (cu.ft) 270 350 430 420 500   Number of augers 1 1 1 1 1   Overall height - no extensions (cm) 231 257 287 244 267   Overall height - no extensions (in) 91 101 113 96 105   Overall width - without options (cm) 254 254 254 282 282   Overall width - without options (in) 100 100 100 111 111   Tread width (cm) 208 208 208.28 267 267   Tread width (in) 82 82 82 105 105   Weight (kg) 2313 2586 2803 4436 4540   Weight (lb) 5100 5700 6180 9780 10010   Drive Planetary Planetary Planetary Planetary Planetary   PTO speed (rpm) 540 540 540 540 / 1000 540/1000   Minimum power requirement for PTO (kW) 37 56 67 67 75   Minimum power requirement for PTO (hp) 50 75 90 90 100   Maximum load (kg) 3062 3969 4876 6396 7484   Maximum load (lb) 6750 8750 10750 14100 16500   Door opening (h x w, cm) 91x99 91x99 91x99 106 x 99 106 x 99   Door opening (h x w, in) 36x39 36x39 36x39 42 x 39 42 x 39   Auger Diameters (cm) 218 218 218 274 274   Auger Diameters (in) 86 86 86 108 108
