Kuhn

ID # 13247385

Kuhn Wheel Rakes

Videos
Call for Price
Overview
Kuhn provides a wide variety of hay-gathering tools giving you the ability to put up better quality hay. Rotary rakes speed hay drying by making fluffy, light and uniform windrows that dry faster. These windrows are easier to pick up with today’s high-capacity Balers and forage harvesters. Mergers help ensure the production of high-quality hay by gentle handling, minimal leaf loss, reduced contamination and a fluffy windrow for better forage harvesting. Wheel rakes provide an economical way to quickly rake hay so you can put up hay fast.
  Features

  Specifications SR 108 GII SR 110 GII SR 112 GII SR 310 SR 312 SR 314 SR 612 GII SR 614 GII SR 616 GII
  Rake Type Carted V-Rake Carted V-Rake Carted V-Rake High Capacity V-Rakes High Capacity V-Rakes High Capacity V-Rakes High Capacity V-Rakes High Capacity V-Rakes High Capacity V-Rakes
  Working width (feet) 18'10" 21'2" 23'4" 17'6" 24'2" 28' 25' 28' 31
  Working width (m) 5.7 6.5 7.3 5.3 7.4 8.5 7.5 8.5 9.5
  Minimum Windrow Width (feet) 3' 3' 3' 3' 3' 3' 3' 3' 3'
  Maximum Windrow Width (feet) 7' 7' 7' 6' 6' 6' 6' 6' 6'
  Minimum Windrow Width (cm) 91 91 91 90 90 91 90 91 91
  Maximum Windrow Width (cm) 213 213 213 183 183 183 183 183 183
  Swath delivery Central and Windrow Turning Central and Windrow Turning Central and Windrow Turning Central - Opt. Windrow Turning Central - Opt. Windrow Turning Central – Opt. Windrow Turning Central - Opt. Windrow Turning Central - Opt. Windrow Turning Central - Opt. Windrow Turning
  Number of Raking Wheels 8 10 12 10 12 14 12 14 16
  Raking Wheel Diameter (m) 1.40 1.40 1.40 1.40 1.40 1.40 1.40 1.40 1.40
  Raking Wheel Diameter (feet) 55" 55" 55" 55" 55" 55" 55" 55" 55"
  Tire type ST 205/75 D-15" ST 205/75 D-15" ST 205/75 D-15" ST 205/75 D-15" ST 205/75 D-15" ST 205/75 D-15" 7.6L-15 7.6L-15 7.6L-15
  Number of Tines per Wheel 40 40 40 40 40 40 40 40 40
  Transport Height (m) 2.5 2.6 2.6 1.96 1.96 1.96 2 2 2
  Transport Height (feet) 8'3" 8'5" 8'5" 6'5" 6'5" 6'5" 6'8" 6'8" 6'8"
  Transport width (m) 2.7 2.6 2.8 2.7 2.7 3.3 - - -
  Transport width (feet) 8'10" 8'6" 9'4" 9' 9' 10'10" 10' 10' 10'
  Tractor hydraulic equipment 1 DBA 1 DBA 1 DBA 2 double acting valves 2 Double Acting Valves 2 Double Acting Valves 2 DBA 2 DBA 2 DBA
  Weight (kg) 576 646 736 1009 1106 1433 1965 2030 2165
  Weight (lb) 1270 1425 1624 2225 2440 3160 4332 4476 4472



Specifications
Model
Wheel Rakes
Category Name
Agriculture
Year
2014
Sale Type
New
Manufacturer
Kuhn
