Kuhn produces innovative Rotary tedders to help speed hay harvesting. Uniformly tedded hay dries faster, preserving valuable nutrients. Kuhn tedders feature a number of innovations, including the reliable, maintenance-free Digidrive coupler, which provides unsurpassed reliability and compact transport and storage.
|
Features |
| |
| |
Specifications |
GF 222 T |
GF 7702 T |
GF 7802 T GII |
GF 8702 T GII |
GF 10802 T GII |
GF 502 THA |
GF 5202 THA |
GF 7802 THA |
GF 13002 |
GF 17002 |
| |
Working width DIN (m) |
- |
7.7 |
7.8 |
8.7 |
10.8 |
- |
5.2 |
7.8 |
13 |
17.2 |
| |
Working width DIN (feet) |
8'6" / 2.60 |
- |
- |
- |
- |
16'5" / 5.0 |
17'1" |
25'7" |
42'8" |
56'5" |
| |
Transport width (m) |
- |
3 |
3 |
3 |
3 |
- |
2.9 |
2.9 |
2.4 |
2.4 |
| |
Transport width (feet) |
7'2" / 2.40 |
- |
- |
- |
- |
9'4" / 2.85 |
9'10" |
9'10' |
7'11" |
7'11" |
| |
Number of rotors |
2 |
8 |
6 |
8 |
10 |
4 |
4 |
6 |
12 |
16 |
| |
Number of tine arms per rotor |
6 |
5 |
7 |
6 |
6 |
6 |
7 |
7 |
6 |
6 |
| |
Linkage |
Drawbar |
Trailed |
Drawbar |
Trailed |
Trailed |
Drawbar |
Drawbar |
Drawbar |
Trailed |
Trailed |
| |
Tire type |
Balloons 15 x 6.00 - 6 |
16 x 6.50 - 8 and 16 x 9.50 - 8 on the 2 central rotors |
Super balloons 16 x 6 50 - 8 |
16 x 6.50 - 8 and 16 x 9.50 - 8 on the 2 central rotors |
16 x 6.50 - 8 and 16 x 9.50 - 8 on the 2 central rotors |
Balloons 15 x 6.00 - 6 |
Superballoons 16 x 6.50 - 8 |
Super balloons 16 x 6 50 - 8 |
Super balloons 16 x 6 50 - 8 |
Super balloons 16 x 6 50 - 8 |
| |
Drive |
Rotors driven by coupling sleeves |
DIGIDRIVE® multiple finger couplings |
DIGIDRIVE® multiple coupling fingers |
DIGIDRIVE® multiple finger couplings |
DIGIDRIVE® multiple finger couplings |
DIGIDRIVE Multiple finger couplings |
DIGIDRIVE® multiple finger couplings |
DIGIDRIVE® multiple finger couplings |
DIGIDRIVE®multiple coupling fingers |
DIGIDRIVE® multiple coupling fingers |
| |
Weight approx. (kg) |
- |
1415 |
1350 |
1480 |
1800 |
- |
530 |
854 |
2550 |
3140 |
| |
Weight (lb) |
495 / 225 |
- |
- |
- |
- |
950 / 431 |
1170 |
1874 |
5622 |
6922 | |
|
| |
|
| |
