ID # 13247270

Kuhn Power Tillers Secondary Tillage

  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Kuhn Power Tillers Secondary Tillage
  • Video Button Hqdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Kuhn Power Tillers and Harrows provide efficient, reliable performance with the versatility to excel in a wide range of working conditions meeting diverse seedbed preparation challenges. These machines can be customized for use in various soils and applications by choosing different types of rotor blades or tines. Durable construction, heavy-duty drives and adaptable features make Kuhn Tillage Tools the machines of choice for you.
  Features

  Specifications EL 23-120 EL 23-150 EL 43-105 EL 43-130 EL 43-150 EL 43-190 EL 53-100 EL 53-130 EL 53-155 EL 53-190 EL 62-130 EL 62-155 EL 62-165 EL 62-180 EL 62-210 EL 82-130 EL 82-155 EL 82-180 EL 82-205 EL 92-180 EL 92-205
  Working width (m) 1.26 1.47 1.07 1.27 1.48 1.89 1 1.3 1.55 1.88 1.3 1.55 1.65 1.8 2.1 1.3 1.55 1.8 2.05 1.8 2.05
  Working width (feet) 49" 57" 42" 50" 58" 74" 38" 50" 60" 74" 50" 60" 65" 70" 83" 51" 61" 71" 81" 71" 81"
  Rotor diameter (mm) 390 390 390 390 390 390 430 430 430 430 - - - - - - - - - - -
  Diameter of roller (inches) - - - - - - - - - - 18" / 450 18" / 450 1'6"/450 18" / 450 18" / 450 21" / 525 21" / 525 21" / 525 21" / 525 21" / 525 21" / 525
  Minimum power requirement for PTO (kW) 7 9 10 12 13 15 13 18 21 24 19 22 24 26 31 24 29 33 38 33 38
  Minimum power requirement for PTO (hp) 10 12 14 16 18 20 18 24 28 32 25 30 33 35 42 33 39 45 51 45 51
  Speed of rotor/s at 540 min-1 (min-1) 241 241 211 211 211 211 244 244 244 244 224 224 224 224 224 212 212 212 212 194/230 194/230
  Maximum authorised tractor power (kW) 18.4 18.4 29 29 29 29 37 37 37 37 48 48 48 48 48 63 63 63 63 70 70
  Maximum Authorised Tractor Power (hp) 25 25 40 40 40 40 50 50 50 50 65 65 65 65 65 85 85 85 85 95 95
  Lateral drive mechanism Chain Chain Chain Chain Chain Chain Chain Chain Chain Chain Gearwheels Gearwheels Gearwheels Gearwheels Gearwheels Gearwheels Gearwheels Gearwheels Gearwheels Gearwheels Gearwheels
  Type of tools C-blades C-blades C-blades C-blades C-blades C-blades C-blades C-blades C-blades C-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades C-blades or L-blades
  Working depth (min.) (cm) 5.1 5.1 5 5 5 5 5 5 5 5 - - - - - - - - - - -
  Working depth (mini) (inches) 2" 2" 6" 6" 6" 6" 6" 6" 6" 6" 2" / 5 2" / 5 2"/5 2" / 5 2" / 5 2" / 5 2" / 5 2" / 5 2" / 5 2" / 5 2" / 5
  Working depth (max.) (cm) 12.7 12.7 15 15 15 15 15 15 15 15 - - - - - - - - - - -
  Working depth (max.) (inches) 5" 5" 49" 49" 49" 49" 49" 49" 49" 49" 7" / 18 7" / 18 7"/18 7" / 18 7" / 18 9" / 23 9" / 23 9" / 23 9" / 23 9" / 23 9" / 23
  Control of working depth With skids as standard With skids as standard With skids as standard + wheels as option With skids as standard + wheels as option With skids as standard + wheels as option With skids + wheels With skids as standard + wheels as option With skids as standard + wheels as option With skids as standard + wheels as option With skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels Choice of skids or wheels With skids. front wheels or rollers
  Weight with packer roller (lb) - - - - - - - - - - - - - - - - - - 1697 / 770 - 1830 / 830
  Weight with cage roller (lb) - - - - - - - - - - - - - - - - - - 1378 / 625 - 1510 / 685
  Weight with skids/wheels (kg) - - 220 235 255 280 250 275 295 295 - - - - - - - - - - -
  Weight with skids/wheels (lb) - - 485 518 562 617 551 606 650 728 646 / 293 728 / 330 794/360 807 / 366 928 / 421 871 / 395 948 / 430 1025 / 465 1124 / 510 1157 / 525 1256 / 570
  Weight approx. (kg) 144 158 - - - - - - - - - - - - - - - - - - -
  Weight (lb) 317 348 - - - - - - - - - - - - - - - - - - -



Specifications
Model
Power Tillers
Category Name
Agriculture
Year
2014
Sale Type
New
Manufacturer
Kuhn
