ID # 13247269

Kuhn Power Harrows Secondary Tillage

  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Kuhn Power Harrows Secondary Tillage
  • Video Button Hqdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
Kuhn Power Tillers and Harrows provide efficient, reliable performance with the versatility to excel in a wide range of working conditions meeting diverse seedbed preparation challenges. These machines can be customized for use in various soils and applications by choosing different types of rotor blades or tines. Durable construction, heavy-duty drives and adaptable features make Kuhn Tillage Tools the machines of choice for you.
  Features

  Specifications HR 3004 D HR 3504 D HR 4004 D HR 5004 DRC HR 6004 DRC HRB 122 HRB 152 HRB 182 HRB 202 HRB 252 D HRB 302 D HRB 303 D HRB 353 DN HRB 403 D
  Working width (m) 3 3.5 4 5 6 1.2 1.5 1.8 2.1 2.5 3 3 3.5 4
  Working width (feet) 9'10" 11'6" 13" 16'5" 20' 4' 5' 6' 6'8" 8'2" 9'10" 9'10" 11'6" 13'1"
  Gearbox Duplex Duplex Duplex Duplex Duplex Single speed gearbox Single speed gearbox Single speed gearbox Single speed gearbox Duplex Duplex Duplex Duplex Duplex
  Minimum power requirement for PTO (kW) 59 66 73 96 110 18 22 26 30 37 44 51 59 66
  Minimum power requirement for PTO (hp) 80 90 100 130 150 25 30 35 40 50 60 70 80 90
  PTO speed (rpm) 1000 1000 1000 1000 1000 540 540 540 540 540 and 1000 540 and 1000 1000/750/540 1000/750/540 1000/750/540
  Maximum authorised tractor power (kW) 184 184 184 184 206 59 59 59 59 103 103 118 118 118
  Maximum Authorised Tractor Power (hp) 250 250 250 250 280 80 80 80 80 140 140 160 160 160
  Transmission With cam type cut-out clutch With cam type cut-out clutch With cam type cut-out clutch With cam type cut-out clutch With cam type cut-out clutch With shear bolt cut-out clutch With shear bolt cut-out clutch With shear bolt cut-out clutch With shear bolt cut-out clutch With adjustable friction slip clutch With adjustable friction slip clutch With cam type cut-out clutch With cam type cut-out clutch With cam type cut-out clutch
  Weight with Maxicrumbler roller (kg) - - - - - - - - - - 975 1085 1296 -
  Weight with Maxicrumbler roller (lb) 2635 / 1195 3087 / 1400 3484 / 1580 5181 / 2350 6393 / 2900 - - - - 1859 / 845 - 2392 2844 3042/1380
  Weight with packer roller (kg) - - - 1820 - - - - - - - - - -
  Weight with packer roller (lb) 2988 / 1355 3550 / 1610 4013 / 1820 - - - - - 1870 / 850 2145 / 975 - - - -
  Weight with Packer PK2 roller (kg) - - - - - - - - - - 1170 1280 1525 -
  Weight with Packer PK2 roller (lb) 3064 / 1390 3604 / 1635 4078 / 1850 5787 / 2625 7253 / 3290 - - - - - - 2822 3362 3638/1650
  Weight with Maxipacker roller (kg) - - - - - - - - - - 1200 1310 1575 -
  Weight with Maxipacker roller (lb) 3131 / 1420 3715 / 1685 4189 / 1900 5952 / 2700 7385 / 3350 - - - - 2277 / 1035 - 2888 3472 3748/1700
  Weight with cage roller (kg) - - - - - - - - - - 965 1075 1300 -
  Weight with cage roller (lb) 2613 / 1185 - - - - 968 / 440 1100 / 500 1210 / 550 1606 / 730 1837 / 835 - 2370 2866 3097/1405



Specifications
Model
Power Harrows
Category Name
Agriculture
Year
2014
Sale Type
New
Manufacturer
Kuhn
