Krone BiG X 480 · 530 · 580 · 630

  • Krone BiG X 480 · 530 · 580 · 630
  • Krone BiG X 480 · 530 · 580 · 630
  • Krone BiG X 480 · 530 · 580 · 630
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Forage harvesters

BiG X 480, 530, 580 and 630 – the compact precision forage harvesters from KRONE for outputs of 490 hp to 653 hp and maximum chopping quality and output as well as superior ease of use and operator comfort.

  • 490-653 hp continuous engine output
  • 6 intake rollers for premium safety and a top quality chop
  • MaxFlow chopping drums with 20, 28 or 36 blades, biogas drum with 40 blades
  • KRONE VariQuick for ultra-quick changeover with or without grain conditioner
  • OptiMaxx roller conditioners measuring 9.8" diameter and 1.9" width for intensive kernel processing
  • KRONE VariLOC for flexible choice of long and short chops
  • KRONE VariStream – spring-loaded plates beneath the chopping drum and at the crop accelerator ensure a continuous crop flow
  • Convenient hoop coupler for easy attachment to the base machine
  • Superb maneuverability from independent wheel suspension and wheel motors
  • Optionally four-wheel drive
  • 3' 3.3" machine width (depending on tires) for easy travel on public roads
Specifications
Model
BiG X 480 · 530 · 580 · 630
Category Name
Agriculture
Year
2025
Sale Type
New
Manufacturer
Krone
highlights

The chopper unitKrone BiG X 480 · 530 · 580 · 630

Wider chopping drum for optimal feeding

It's not just the number of blades that accounts for a good quality chop. The thickness of the mat that passes through them and therefore the width of the chopping drums are just as important. Therefore KRONE designed a wider 2' chopping drum for the BiG X 480, 530, 580 and 630 which carries the customary high chopping quality of the high-capacity foragers with 2' 7.2" drums over to the smaller models.



models
  BiG X 480 BiG X 530 BiG X 580 BiG X 630
Engine MTU 6R 1300 MTU 6R 1300 MTU 6R 1500 MTU 6R 1500
No. of cylinders 6 6 6 6
Engine capacity (l) 12.80 12.80 15.60 15.60
Continuous engine output (kw/hp) 360 / 490 390 / 530 436 / 593 480 / 653
Max. Continuous X-Power chopping output (kW / hp) 338 / 460 368 / 500 408 / 555 452 / 615
Max. Continuous Eco-Power chopping output (kW / hp) - - 338 / 460 338 / 460
