EasyCut F 280 M, F 320 M, F 360 M: The EasyCut M front mowers stand out for their extremely low weight which makes them the first choice for customers who farm hilly terrain or prefer spreading the material across the full width. The coupling points on these machines couple easily to compact special crop tractors.

EasyCut F 280, F 320, F 360: These are our front-mounted models which cut at widths of 2.71 m (8'10") and 3.57 m (11'9") and use powered top hats that enhance the crop flow to the rear. EasyCut F 320 and F 360 operators will alter the swathing width by selecting the appropriate top hats.

EasyCut F 320 CV: This front mower has the CV conditioner with steel tines and cuts at a width of 3.16 m (10'4.5"). The manual or optional hydraulic suspension springs maintain an optimum ground pressure.

EasyCut F 360 CV, F 360 CR: The front mowers EasyCut F 360 CV with steel tine conditioner and EasyCut F 360 CR with roller conditioner cut as wide as 3.60 m (11'10"), a work width that ensures generous overlapping in combinations.

EasyCut – uniquely KRONE: The situation is familiar to every farmer – a disc hits a foreign object, gets damaged and needs replacing. In this situation, KRONE SafeCut offers a maximum of protection. The DLG Gold winning new disc shear-off system brings a new level of protection and operational reliability to the EasyCut mowers with and without CV conditioner. SafeCut is standard equipment on all EasyCut disc mowers.

EasyCut – the better cut: The wedge-shaped cutterbar adjusts through a large setting range to cut short stubble in meadows and pastures and longer stubble in longstemmed field crops. EasyCut cuts blockage-free and clean. Benefitting from massive double spur gear bearings that are spaced at large gaps, the cutterbars are heavy-duty and hardwearing.

The original: The established system of satellite gears is a KRONE development. Ever since it was introduced in 1989, this design has proven extremely well all over the world. A driveline of massive spur gears with up to 66 teeth transfers the power all the way down to the very last disc. Revolving at lower speeds, the large-diameter gears always have a number of teeth in mesh at any one time, giving quiet running, ultimate efficiency and maximum longevity. With each of the auxiliary gears driving just one disc, it is exposed to only minimum mechanical strain.

Sleek engineering unveiled: This photo shows the EasyCut F 320 M model stripped off its flexible guards, which obviously cover an uncluttered design. Weighing in about 500 kg (1,102 lbs), 620 kg (1,367 lbs) and 680 kg (1,499 lbs), the EasyCut F 280 M, F 320 M and F 360 M front mowers stand out for their light build and easy handling. Doing without hydraulic control, they offer absolutely easy and quick attachment and removal. The cutterbar suspends from struts that are arranged just behind the hats – an ideal design for a uniform crop flow. Like all other models, these mower beds are wedge-shaped, fully welded and feature our SafeCut system as well as quick-changing knives.

Proven in the field - Very hilly terrain poses a special challenge to every mower. The front-mounted KRONE EasyCut F 280 M and F 320 M disc mowers take on that challenge. Working at widths of 2.73 m (9') and 3.16 m (10'4.5"), these models present the optimum solution to deal with steep slopes. Among the advantages of this light-weight and very compact mountain mower are its compact design, the centre of gravity arranged close to the tractor, a perfect cut on steep slopes as well as excellent tractor attachment options. The EasyCut 360 M with its enormous work width is an excellent match for tractors with huge trackwidths and offers a generous overlap when used in combination with rear mowers.

Perfect ground hugging: The pushing suspension design provides a generous vertical travel and combines with long skids and an optional telescoping top link to provide optimum ground hugging in every way. Mounted extremely close to the tractor, the mower travels very little when gliding over undulations. The design reduces wear on the driveshaft and enhances operator overview.

A perfect system: EasyCut F 280, F 320 and F 360 are mowers that adapt to any type of ground contours – in and across the direction of travel. The pushed design allows for plenty of up and down travel – the ideal design for rough terrain. In addition, the compact build offers an excellent overview in the field and an excellent transport stability for safe travel on public roads. As it mounts close to the tractor, the linkage travels through a smaller angle and less strain is put on the driveshaft.

Quality forage stems from quality cuts: The KRONE front mower impresses by ease of operation, a clear design and outstanding functionality. The compact and light mower is pushed over the surface. Suspended by a pivoting headstock in its centre of gravity and close to the tractor's front wheels, the unit benefits from very little travel to produce perfect cuts, fast crop re-growth and uncontaminated forage.

The secret behind perfect swathing: The KRONE EasyCut EasyCut F 280, F 320 and F 360 front mowers feature massive top hats, which sit on the right and left end of the cutterbar. Arranged behind the discs, they feed the material in a continuous fl ow to the rear. So the tractor wheels will not run on the crop but straddle the swath and the harvester will gather it easily and without loss.

For the best forage: Cutting and conditioning in one pass, the KRONE front mowers with CV steel tine conditioner are specialist machines to cut quality forage for on-farm use. The large 64cm (2'1") diameter rotor copes with even the longest crops. The angled V tines feed the material past the baffle plate, treating it across the full work width.

It’s intensive: V-type steel tines at steep angles and an adjustable baffle plate give effective treatment, reduce wear and adapt to the current crop conditions.

Hydraulic pressure control: The optional hydraulic spring tensioning system offers quick and convenient control on the move. As a result, the machine gives clean cuts and therefore high-quality forage.
