Overview

This is where future champions fight for victory, whether it be at Loretta Lynns or a regional championship, the 85 SX is regarded as a winning bike in this scene. With the most powerful engine in the field and an ultra-light, sturdy chassis, it has nothing to fear from any full-size bike.
 STABLE IN EVERY SITUATION

56dac964c4
FRAME

The frame made of high quality, chrome-molybdenum steel with a lightweight aluminium rear end guarantees maximum stability at a minimum weight. Its hardwearing plastic coating is still in a classy anthracite metallic.

D9b3f60d65
GRAPHICS

The revamped, cool graphic design provides the bike with a striking new appearance.
BODYWORK

The bodywork is designed ergonomically and functionally in such a way that the motorcycle is in perfect harmony with the rider.

10c4aa31d6
HANDLEBAR

The 85 SX is equipped with an extremely sturdy, tapered Renthal handlebar made from high-grade aluminium alloy, which features an offset specially designed to meet the demands of motocross.

 MASTERS THE TOUGHEST TRACKS


03ab933afd
CHASSIS

The proven 43 mm upside-down fork with 270 mm of suspension travel and the PDS shock absorber ensure optimum traction and suspension comfort on the KTM 85 SX. Rebound and compression damping can be adapted individually to track and rider in no time at all.


4108ce5777
SWINGARM

As before, the newly developed swingarm is manufactured from lightweight aluminium in the form of a single casting. The very latest calculation methods have allowed weight to be reduced by 500 grams. Furthermore, newly designed chain links and brake-hose brackets plus the proven chainguide from the full-size SX models have been employed.

 WHEELS AND BRAKES
.
Cc1ec91c76
WHEELS

The wheels are fitted with lightweight, CNC-machined hubs and high-end Excel rims, plus black-coated spokes with lightweight aluminium nipples, guaranteeing highest levels of stability while keeping weight to a minimum. The 85 SX is now equipped with the very latest generation tyre from MAXXIS, featuring a profile that guarantees optimum grip on every surface.


Be1fc92c89
BRAKES

The greater the power, the more important the brakes. Here the products from brake specialist FORMULA live up to all the expectations of young racers. Together with the lightweight wave brake discs (220/210 mm f/r), the proven, radially mounted brake calipers (4 pistons at the front, 2 at the rear) set the benchmark in terms of application and brake performance.

 UNRIVALLED POWER
1759d0be89
CRANKSHAFT

Thanks to the optimally dimensioned connecting rod, the crankshaft excels with minimum vibration and maximum durability.
ENGINE

State-of-the-art 2-stroke technology in conjunction with a precise 6-speed transmission and a hydraulic clutch provide the basis for the superiority of the 85 SX in all junior race series.

1f4a1f7975
CYLINDERS

The compact cylinder with 47 mm bore ensures that the 85 SX achieves peerless performance thanks to the ports dimensioned for optimum gas flow and the centrifugally-controlled exhaust valve. A reworked rear transfer port guarantees even better durability.

485e018f36
AIRBOX

What's good for the bigger KTM offroad bikes is good for the 85 SX: air filter replacement without tools in a matter of seconds.
COOLING

Constant temperature control and hence consistently high performance are ensured by an intelligent cooling circuit with integrated crankcase cooling and two radiators.

E79d2f33a7
CLUTCH

The 85 SX engine is equipped with a modern, hydraulic clutch actuation system from FORMULA, which guarantees smooth and very precise clutch control.




Specifications
Model
85 SX 17/14
Category Name
Motorcycles
Year
2015
Sale Type
New
Manufacturer
KTM
Engine Size
84.93 cc
ENGINE Design
1-cylinder 2-stroke engine, water-cooled, with reed intake and exhaust control
Bore
47 mm
Stroke
48.95 mm
Transmission
6-gear, claw shifted
Secondary Ratio
14:46
Ignition
Moric Digital 2M1
Weight Without Fuel, Approx
67.5 kg
Fuel Tank Capacity, Approx
5.0 l Unleaded premium fuel (98 octane), mixed with 2-stroke engine oil (1:40)
Seat Height, Unloaded
855 mm
Ground Clearance, Unloaded
352 mm
Wheelbase
1,290±10 mm
Steering Head Angle
Steering head angle
