EvoCab II optimizes visibility with 3-pillar design

The new large spacious EvoCab II is specifically developed by HARDI with its “3-pillar design”, which provides a new standard for visibility with more than 320° around the sprayer.

The cabin is equipped with a pressurisation system, a dust filtering of fresh air, an aerosol and vapor filtering to protect the driver and fulfill the Class 4 requirements.

The new climate control system has been tested intensively in climate chamber in order to bring highest driver comfort in warmest condition.

FloatRide suspension

By equipping the ALPHA with the optional FloatRide, the standard coil spring suspension is replaced by airbags. This ensures even more boom stability and maintains balance of the ALPHA in strong slope. The chassis’ height will be maintained whatever tank volume.

By allowing for individual wheel movement, the ALPHA provides a maximum comfort, even at high spraying speeds through a wheel travel of 33 mph.



Hydraulic Track width Adjustment

 The ALPHA evo EcoDrive with FloatRide suspension can be equipped with Hydraulic Track width Adjustment. This Hydraulic Track width Adjustment axle allows a track width from 88 to 126 in. (depending on tire dimensions).

The driver will set his track width from the cab display and will be ready to drive. This will allow changing track width from the road to the field and from cereal crop to maize, row crop or vegetable with a variation of 1 m between minimum and maximum.



HARDI SprayCenter

The pilot can operate all spray and hydraulic functions directly from the cab with the right hand located arm rest SprayCenter. The HC 9600 12.1’’ touch screen controller is featuring an integration of all electronic functions as AutoTrack, AutoHeight, AutoSectionControl and other intelligent features as AutoFill, AutoWash, AutoAgitation etc.

All functions are fully controlled from the cab and underline the level of optimization, the pilot can gain from this machine.

HC 9600

All the main spraying functions are operated with the fi ngertip multifunction joystick in conjunction with the HC 9600 12.1” touch screen spray controller to provide the highest level of performance and application precision.

The HC 9600 controller provides the growers with a powerful, full-featured precision farming tool for guidance, data logging, split-screen for better overview, application report generation, automated steering and more.
