ID # 13869597
HLA Snow 6000 Series
Overview
| |
|
Features |
- 2 Year Warranty
- 35° Angle with Crossover Relief Valve Protection
- Lateral Float
- Mouldboard Profile
- Nitrate Rods on Angle Cylinders
- Replaceable, Reversible Cutting Edge
- Skid Shoes
- Spring Trip Cutting Edge
- Floating Blade Hinge
|
|
Specifications |
| |
| Part # |
Approx. Weight (LBS.) |
Length (in.) |
Overall Road Width (Angled) (in.) |
Snow Clearing Width (Angled) (in.) |
Mouldboard Height |
Max Operating Weight (LBS.) |
|
SB600010 |
3,350 |
120 |
112 |
98.5 |
53" |
60,000 |
|
SB600012 |
3,675 |
144 |
132 |
118 |
53" |
60,000 |
|
SB600014 |
3,950 |
168 |
152 |
138 |
53" |
60,000 |
|
SB600016 |
4,400 |
192 |
172 |
158 |
53" |
60,000 |
|
SB600018 |
4,705 |
216 |
192 |
178 |
53" |
60,000 |
|
SB600020 |
5,060 |
240 |
212 |
198 |
53" |
60,000 | |
